11.3 Electronic control panel alarms

•
When the electronic control panel detects the boiler is running dry, all LEDs of key pad start blinking.
•
When the control panel detects problems on the flowmeter, the LED of the dose pushed starts to flash.
•
The product dispense is automatically interrupted after 5 minutes (Time-out). The led keeps on blinking
until a new selection is made.
12.

Heating-up liquids

a) Place the steam wand, -see (1) Fig. 1-, above the tray and open a bit the steamer knob, -see (2) Fig. 1-
, in order to allow condensed water drops go out.
b) Turn the steam knob.
c) Place the steam wand inside the liquid wanted to be heated up.
d) Open up the steam knob and it will start to heat the liquid ( do not take it out from the liquid until closed,
you could be injured with the steam).
e) Once this process has finished, put the steam wand on the tray and open up the steam knob to clean
leftovers of milk or other liquids, inside the steamer. Turn the knob and clean the outside of the steamer with a
damp cloth.
13.

Hot water for infusions

•
Place the recipient under the water tap, -see (13) Fig. 1-, where you want to have hot water.
•
Open up the water knob, -see (3) Fig. 1,- until you have the desired volume of water.
•
Close it down.

14. Coffee machine with built-in grinder

1 BEAN HOPPER LID
2 BEAN HOPPER
3 BEAN HOPPER GATE
4 COFFEE GRINDING ADJUSTMENT DISK
5 GRINDING TRIGGER
6 GROUND COFFEE DOSAGE DEVICE LID
7 GROUND COFFEE DOSAGE DEVICE
8 GRINDER ON/OFF SWITCH
9 DOSAGE DEVICE LEVER
10 COFFEE TAMPER
11 GROUND COFFEE OUTLET
Previous operations before starting-up the coffee grinder:
a) Check the bean hopper (2) is correctly placed.
b) Place the bean hopper gate (3) in a locked position, in order to avoid the pass of the coffee beans to
the grinder, just pressing it.
c) Lift up the bean hopper (2) lid (1), fill the bean hopper with beans and close it again
d) Slide the bean hopper gate (3) to a position allowing the coffee getting into the grinder, pull from the
bean hopper gate.
How to obtain a ground coffee dosage:
a) Place the portafilter over portafilter holder (7), which it is just under the ground coffee outlet.
b) Pull from the ground coffee dosage device lever (9) towards you in order to obtain a dosage and leave
the coffee dosage device lever free.
c) Place the portafilter under the coffee tamper (9) and push it upwards in order to compact the coffee.
Adjusting the grinding degree of coffee:
You can obtain two grinding degrees (thin ground coffee/coarse ground coffee).
a) If you want to obtain thin ground coffee. Maintain pressed the millstone trigger (5) in order to turn
right the setting grind wheel (4), then set it free.
b) If you want to obtain a coarse ground coffee. Maintain pressed the millstone trigger (5) in order to
turn left the setting grind wheel (4), then set it free.
14
6 5
7
8
9
10
11
ENGLISH
1
2
3
4
