The manufacturer is not liable for the injuries or damages on people and/or animals, as well as
damages on equipment, caused by a improper installation of the coffee machine.
5. Water loading in the boiler
The water level must be between the maximum and the minimum level. To increase the water level press the
manual boiler refill.
- Machines with electronic control panel have electronic boiler refill control.
- Machines without water level indicator, have electronic boiler refill control.
6.

Main power switch

For all Mini models:
•
The general switch is luminous.
For all models:
•
The general switch is a knob, -see (8)Fig.1
7.

Pressure gauge

The pressure gauge shows
the pressure
inside the boiler.
Water level indicator
Manual boiler refilling
Pressure-Temperature Ratio
Temperature (ºC)
125
120
115
110
0,6 0,7
Pressure (Bar)
ENGLISH
Fig. 2
OFF ON
Fig. 3
0,8 0,9 1 1,1 1,2
11
