NEC MultiSync LCD1700NX A Service Manual page 62

Item
Pixel frequency
Horizontal frequency
Line time total
Horizontal active display
Horizontal sync pulse
Horizontal back porch
Horizontal front porch
Horizontal sync polarity
Vertical Frequency
Frame time total
Vertical active display
Vertical sync pulse
Vertical back porch
Vertical front porch
Vertical sync polarity
Full scan mode
Preset No.
Abbreviation VESA 1280 x 960 60Hz
fc 108.00MHz
fh 60.00kHz
Th
16.67µs
Thd
11.85µs
Thp
1.04µs
Thb
2.29µs
Thf
0.89µs
fv 60.00Hz
Tv 16.67ms
Tvd 16.0ms
Tvp 0.05ms
Tvb 0.60ms
Tvf 0.016ms
17
1800CLK
1280CLK
112CLK
312CLK
96CLK
POS/NEG
1000H
960H
3H
36H
1H
POS/NEG
Expansion
4-12
18
VESA 1152 x 900 60Hz
94.50MHz
61.85kHz
1528CLK
16.17µs
1152CLK
12.19µs
128CLK
1.35µs
208CLK
2.20µs
64CLK
0.42µs
POS/NEG
66.00Hz
15.15ms 937H
14.55ms 900H
0.07ms 4H
0.50ms 31H
0.03ms 2H
POS/NEG
Expansion
