ML Switch User Guide

IP-r (IP Address issued by the DHCP server)

To configure the ML Switch for IP-r, set the two rotary switches to give the ML Switch unique identifier. The ML Switch should then be
connected to the network.
2. nEt. From the function menu you can now select nEt
To ease setup, a single network mask length value is used. If the address has been specified with a network mask value in dotted IP
format e.g. 255.255.255.0 then the table below gives the conversion:
Warning
Ensure that all power is
switched off before
installing or maintaining
this product
Press enter and the display will show "IP-r", press enter
You can now view only the address given by the DHCP server
Mask Length
255.255.255.252 30
255.255.255.248 29
255.255.255.240 28
255.255.255.224 27
255.255.255.192 26
255.255.255.128 25
255.255.255.0 24
Mask Length Mask
255.255.254.0 23 255.254.0.0
255.255.252.0 22 255.252.0.0
255.255.248.0 21 255.248.0.0
255.255.240.0 20 255.240.0.0
255.255.224.0 19 255.224.0.0
255.255.192.0 18 255.192.0.0
255.255.128.0 17 255.128.0.0
255.255.0.0 16 255.0.0.0
Revision 1.2D
Length
15
14
13
12
11
10
09
08
Page 16 of 17
