Nitecore EA1 User Manual

ALL-ROUND Flashlight Expert
Features
• CREE XP-G (R5) LED
• Maximum output of up to 180 lumens
• High efficiency circuit enables maximum runtime of up to 80 hours
• 5 brightness levels
• Momentary push-on strobe and SOS modes
• Dual electronic switches ensure very easy user interface
• Secondary red light mode (0.2 lumens)
• Power indicator light also serves as battery voltage indicator (accurate to
0.1V)
• Power indicator light serves as standby indicator light when powered down
• Broad voltage circuit accepts both rechargeable and non-rechargeable
Lithium batteries
• Toughened ultra-clear mineral glass with dual-side anti-reflective coating
• Elaborate alloy reflector is purpose-designed for exceptionally long throw
• Constructed from aero grade aluminum alloy
• HAIII military grade hard-anodized
• Stainless steel bezel retaining ring protects core components from damage
• Detachable two-way anti-rolling clip
• Waterproof in accordance with IPX-8 (2 meters submersible)
• Tail stand function
Dimensions
Length: 81mm
Head Diameter: 25.4mm
Tail Diameter: 19mm
Weight: 47.5g (without battery)
Accessories
Quality holster, lanyard, spare O-ring
Battery Options
Primary AA battery
Rechargeable AA battery
Primary AA Lithium battery
Primary LiFePO4 battery
Rechargeable Li-ion battery
Note:
When EA1 is driven by primary LiFePO4 battery or rechargeable Li-ion battery, it can
result in one of the below situations:
1. EA1 brightness level is greatly increased
2. EA1 circuit can not accurately detect the battery voltage
Brightness & Runtime
TURBO HIGH
180 100
LUMENS LUMENS
— 2 20
h
109m
3000cd
1.5m
IPX-8, 2m
SIZE Nominal voltage Compatible
AA 1.5V Y (Recommended)
AA 1.2V Y (Recommended)
L91 1.5V Y (Recommended)
14500 3.2V
14500 3.7V
MID LOW
40 12
LUMENS LUMENS
min 5 17
h h
(Beam Distance)
(Peak Beam Intensity)
(Impact Resistant)
(Waterproof AND Submersible)
Thanks for purchasing NITECORE!
®
EA1
NOTICE
The stated data has been measured in accordance with the international
flashlight testing standards ANSI/NEMA FL1, using one high quality AA
Ni-Mh rechargeable battery (1.2V, 2500mAH) under laboratory
conditions. The data may vary in real-world use due to different battery
usage or environmental conditions.
Operation instructions
Battery installation
1. Unscrew (counterclockwise) and remove the tail cap.
2. Insert one AA or other compatible battery with the positive pole of the
battery pointing toward the head.
3. Replace the tail cap and fasten tightly.
WARNING
Always ensure battery is inserted with the positive (+) end pointing
toward the flashlight head. If incorrectly installed, the flashlight will not
Y
work.
Y
Switching ON/OFF
To switch ON: Press the "ON/OFF" button once to turn the light on.
To switch OFF: Press the "ON/OFF" button once again to turn the light
off.
Note: When EA1 is off, the power indicator (red light) will flash once
every 3 seconds to act as a locator. In this mode, the EA1 consumes a
very little amount of current (about 0.15mA) to maintain working of the
MICRO
built-in MCU and power indicator. In this mode, one AA battery will last
2
about 2 years.
LUMENS
80 Brightness Selection
h
With the flashlight switched-on, each time you press the "MODE" button,
it will go through the different preset brightness levels as follows:
ultra-low mode→low mode→medium mode→high mode then repeat. In
this mode, the flashlight has a memory function. It can memorize the
selected brightness after turning the light off. The next time turning on
the light, it automatically resumes to the previously selected mode.
Entering Turbo Mode
With the flashlight switched on, press the "MODE" button for more than 1
Second, EA1 will enter Turbo mode. Press the MODE button again, the
flashlight will retreat from turbo brightness and resume to previous
brightness. In Turbo mode EA1 circuit will deliver maximum current to
make brightness as high as possible.
