Nitecore EA42 - High Intensity Spotlight Manual

Table of Contents

Contents

1 Batteries Installation
2 Technical Parameters
3 Features
- 3.1 Battery Options
4 Operation Instruction
- 4.1 Batteries Installation
5 On/Off Operation
6 Changing Brightness Level
7 Direct Access to Turbo/Ultralow
8 Positioning
9 Lockout/Unlock
10 Power Tips
11 Accessing Special modes (Strobe/ Beacon / SOS)
12 ATR (Advanced Temperature Regulation)
13 Replacing Batteries
14 Maintenance
15 Warranty Service
16 Documents / Resources
- 16.1 References
- 16.2 Download manual

Batteries Installation

Technical Parameters

FL1 STANDARD	TURBO	HIGH	MID	LOW	UTRALOW	STROBE	SOS	BEACON
	1800 LUMENS	850 LUMENS	300 LUMENS	55 LUMENS	1 LUMEN	1800 LUMENS	1800 LUMENS	1800 LUMENS
	*30min	1h45min	4h45min	20h	280h	─	─	─
	353m	259m	152m	63m	10m	─	─	─
	31200cd	16700cd	5750cd	1000cd	25cd	─	─	─
	1.5m (Impact Resistant)
	IPX8, 2m (Waterproof AND Submersible)

NOTICE: The above data has been measured in accordance with the international flashlight testing standards ANSI/ NEMA FL1 using 4×1.2V 2450mAh AA Ni-MH batteries under laboratory conditions. The data may vary slightly during real-world use due to battery type, individual usage habits and environmental factors.

* The runtime for Turbo mode is the testing result before starting temperature regulation.

Features

AA Battery Powered High Intensity Spotlight
Utilizes a CREE XHP35 HD LED with a max output of 1800 lumens
Integrated "Precision Digital Optics Technology" provides extreme reflector performance
Boasts a peak beam intensity of 31,200cd and a throw distance of 353 meters
Dual switch offers a user-friendly interface
5 brightness levels and 3 special modes optional
High efficiency circuit board provides up to 280 hours runtime
Power indicator beneath the switches displays remaining battery power (Patent No.: ZL201220057767.4)
Built-in Advanced Temperature Regulation module
Toughened ultra-clear mineral glass with anti-reflective coating
The head is constructed from aero grade aluminum alloy with HAIII military grade hardanodized finish
The tube is constructed from Polycarbonate (PC) material
Waterproof in accordance with IPX8 (two meters submersible)
Impact resistant to 1.5 meters

Dimensions	Accessories
Length: 168mm (6.61")	Quality holster, lanyard, spare O-ring
Head diameter: 40mm (1.57")
Side length of tail: 34.6mm×19.6mm (1.36"×0.77")
Weight: 127.7g (4.5oz)

Battery Options

	SIZE	Nominal voltage	Compatible
Ni-MH battery	AA	1.2V	Y (Recommended)
Alkaline battery	AA	1.5V	Y
Primary AA Lithium battery	L91	1.5V	N
Rechargeable Li-ion battery	14500	3.7V	N

NOTE: When using alkaline batteries, Turbo mode (1800 lumens) may be inaccessible. Please choose the high quality alkaline batteries, otherwise it may lead to sudden shutoff in Turbo mode.

Operation Instruction

Batteries Installation

Loosen the securing ring that connects the head and the tube and pull out the tube as shown in the diagram below
Ensure batteries are inserted with the negative (-) ends pointing towards the spring.
After battery installation, assemble the head and the body tube together by carefully aligning the pins on the body tube to the grooves on the back of the light head. Rotate and tighten the securing ring afterward.

NOTE: After battery installation, the power indicator beneath the switches will blink to indicate battery voltage. Please refer to the "Power Tips" section of this manual for details.

Do not mix rechargeable and non-rechargeable batteries.
Do not mix batteries of different types/brands.
Ensure the batteries are inserted correctly. The EA42 will not operate if batteries are incorrectly inserted.
When the flashlight is kept in a backpack, please lockout the EA42 to prevent accidental activation of the flashlight; When it is left unused for extended periods of time, please remove all batteries to prevent battery leakage.

On/Off Operation

Turn on: When the light is off, tap the On/Off switch to turn on the light.

Turn off: When the light is on, tap the On/Off switch again to turn off the light.

Changing Brightness Level

When the light is on, tap the mode switch to cycle through "Ultralow-Low-Mid-High-Turbo". (The EA42 memorizes its previously used brightness level and returns to it the next time it is turned on. When batteries are reinstalled, the light will reset to ultralow.)

Direct Access to Turbo/Ultralow

Direct Access to Ultralow: When the light is off, press and hold the On/Off switch for 1 second to enter Ultralow.

Direct Access to Turbo: When the light is off, press and hold the mode switch for 1 second to activate Turbo mode. Keep holding the mode switch and the light will enter momentary Turbo mode which will turn off when the pressing is released.
When the light is on, press and hold the mode switch to momentarily activate Turbo mode. The light returns to its previously brightness level once the pressing is released.

Positioning

When the light is on, press and keep holding the On/Off switch to turn off the light and activate the positioning function
The blue indicator beneath two switches blinks once every 2 seconds to signal the location of the light.
When positioning light is on, standby time is about 6 months; When the positioning light is off, standby time is about 1 year.
To switch off the positioning light, either tap the On/off switch which will turn on the light, or tap the mode switch which will activate the power indicator.

Lockout/Unlock

Lockout: The lockout mode is designed to prevent the light from accidental activation. To enter lockout mode, press and hold both switches simultaneously until the light flashes once and turns off. The light will not respond to any switch press in the lockout mode. The positioning light is also turned off.

Unlock: To exit lockout mode, simply press and hold both switches until the light turns on again.

Power Tips

When the light is switched off, tap the Mode switch once to activate the built-in power indicator underneath the switches. The power indicator will flash to indicate the remaining battery level:

3 flashes represent battery level above 50%.
2 flashes represent battery level below 50%.
1 flash represents battery level below 10%.
NOTE: When the light is in use, the indicator will flash slowly if the battery level is below 50% and flashes rapidly if the battery level is below 10%.

Accessing Special modes (Strobe/ Beacon / SOS)

When the light is off, tap the Mode switch twice successively to turn Strobe on. Tap the Mode switch again to cycle through Beacon-SOS-Strobe. Turn off the light to exit Special Modes.

ATR (Advanced Temperature Regulation)

With Advanced Temperature Regulation module, the EA42 regulates its output and adapts to the ambient environment, maintaining optimal performance.

Replacing Batteries

When the battery level is low, the blue power indicator will flash quickly, the light output will become dim and/or the mode switch will no longer be able to adjust the brightness. In these situations, batteries should be replaced.

Maintenance

Every 6 months, threads should be wiped with a clean cloth followed by a thin coating of siliconbased lubricant.

Warranty Service

All NITECORE ® products are warranted for quality. DOA/defective products can be exchanged for replacement through a local distributor/dealer within the 15 days of purchase. After 15 days, all defective / malfunctioning NITECORE ® products will be repaired free of charge for a period of 60 months from the date of purchase. After 60 months, a limited warranty applies, covering the cost of labor and maintenance, but not the cost of accessories or replacement parts.

The warranty is nullified in all of the following situations:

The product(s) is/are broken down, reconstructed and/or modified by unauthorized parties.
The product(s) is/are damaged through improper use. (i.e. reverse polarity installation)
The product(s) is/are damaged by leakage of batteries.
