MASTER (AND PHONES)
The main Program outputs (labeled PGM on TriCaster's faceplate) are controlled by the Gain knob and Balance
control in the Master sub-panel, located at far-right in the Audio Mixer tab. Just above this is a simple level
control for the Phones output.
Hint: Shift + double click Gain knobs to restore their default values (0dB).
STREAM
The Stream sub-panel provides a method of independently adjusting (stereo) audio levels sent to the network
when streaming is enabled. An important addition to this control group is the Source drop-down menu. This
allows you to supply sound to the Streaming output exclusively from one of the following selections:

DDR – audio from the DDR output is sent to the streaming output.

GFX 1 or 2 –audio from the corresponding player is sent to AUX output connectors.

Internal – All internal audio sources combined.

All –a supplementary program output channel with independent level control.

Solo – only sources with their Solo switches enabled are sent to the streaming output.

3.10 DESKTOP OPTIONS

Several very useful options are presented in the Desktop Options menu.
Open the menu by clicking the gear button at extreme right (just above
the large tabbed panes occupying the lower third of the Live Desktop).
Enable Tabs Follow Preview Row for All Inputs to cause the tabbed
control panel for all appropriate sources (VI, DDR, GFX, etc.) to be
displayed automatically when the source is newly selected on the
Switcher's Preview row.
When Tabs Follow Preview for Virtual Inputs is checked, the tab shown updates only when you select a Virtual
Input on Preview.
Hint: Control surface operations can sometimes result in a tabbed module that you want to view being obscured
because related Desktop Options are enabled. Press the corresponding control surface Delegate button again to
re-display the tabbed pane you are interest in.

3.11 SHUTTING DOWN

When your production has ended, click the Close [X] button at right in the Live Desktop titlebar. This returns you
to the Session page, where you can manage content from the session, or click the large 'back' arrow to return to
the Home page.
Figure 72
45
