The Format menu determines what video format is supplied by the Aux output connectors. This setting is
independent of session format, and allows multiple formats to be transmitted (and recorded) simultaneously.
MULTIVIEW
The Output Configuration panel has another control group labeled Multiview. These settings govern the
secondary display port on TriCaster's rear panel. You might use this output for subsidiary monitoring purposes,
or perhaps to supply a projection system. Controls in the tabbed panel determine what display is shown and
what resolution is supplied to the output.
The Screen Layout menu provides a number of optional displays, including Program, Preview and FX monitors,
along with a number of useful 'multi-bridge' layouts, and a large, highly visible Waveform/Vectorscope option.
Set the VGA Output Resolution for Multiview to the native resolution of the external device you plan to connect.
AUDIO
TriCaster's audio input and output streams are individually configured using control groups located in the Audio
Mixer tab.
Figure 21
MEDIA PLAYERS
All three Media Players in TriCaster 40 (DDR, GFX1 and GFX2) support playback of common audio file formats
such as MP3 or WAV. (The DDR also plays video clips with embedded sound). Each player has its own control
group in the Internal Audio tab. The controls and options for internal sources are similar to those we discussed
when considering Internal Audio (Section 2.3.3), so we won't repeat that information here.
