4

Table of Contents

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Important Product Warnings & Safety Instructions
®
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
You MUST use the Power Supply provided with your unit or you VOID
the Key Digital
Warranty and risk damage to your unit and associated
®
equipment.
Please read all instructions to insure safe operation of the product.
© 2013 Key Digital, Inc. All rights reserved.
1
2
3
3
3
4
4
6
. . . . . . . . . . . . . . . . . . . . . . .
7
8
8

About KD-HDDA1X1Pro

The Phantom Series
KD-HDDA1X1Pro HDMI extender repeats HDMI signals up
to 65 ft. and equalizes the signal for reliable transmission over greater distances
than standard cabling. Up to 3 KD-HDDA1X1Pro may be daisy-chained. Utilizing
the latest HDMI standards: 3D, 4K and ARC (Audio Return Channel). The KD-
HDDA1x1Pro also features a built-in library of 16 EDID files, and the capability to
force HPD (Hot Plug Detection).
Key Features
Capable of extending 1080p resolution up to 65 ft. (20 meters)
Auto-adjustment of equalization, buffering and amplification
16 built in EDID settings
Advanced HDMI features:
3D, 4K, ARC (Audio Return Channel)
HDCP compliant
HDMI audio de-embedding to external analog or
digital audio outputs
Capable of forcing HPD (Hot Plug Detection)
Key Benefits
Built in EDID Library settings permit passing 3D signals
Allows extending HDMI signals for longer runs than normally possible
Ultra small design for many applications
Fixes HDMI related problems, such as HDCP, EDID and HPD issues
Allows audio to be de-embedded from the HDMI cable and sent to audio
distribution systems, such as amplifiers or switches
Can force HPD to ensure a source always puts out a signal
Accessories
5V 2A DC Power Supply
