VRinsight MS Panel User Manual page 9

VRinsight
Multi Switch Panel
Step 10
Step 11
Step 12
Copyright © 2010 VRinsight | SimWare Simulations
- The Axis Calibration for Rudder window appears.
- Move S3 slider, which is recognized as Rudder,
up and down.
- Click once more the Next> button.
- The Axis Calibration for Throttle windows appears.
- Move S4 slider, which is recognized as Throttle,
up and down.
- Click Next> and finish the Calibration Wizard.
This concludes the calibration procedure for the
sliders and rotary encoders R1 and R2.
- Select the Test tab as shown below.
- Move and/or press all Multi Switch panel buttons,
switches, knobs and sliders and check for their
correct output on the usb pad properties window.
- When you are finished with testing are the switches,
buttons, sliders and knobs, click the OK button.
Assignment Procedures
Version: 1.00 | November 8, 2010
