Laminar Research X-Plane 9.X - VRinsight MS Panel User Manual

VRinsight
Multi Switch Panel

Laminar Research X-Plane 9.x

Step 1
Step 2
Step 3
Copyright © 2010 VRinsight | SimWare Simulations
- If not yet done, connect the Multi Switch Panel USB
cable to a USB 2.0 receptacle.
- Start X-Plane 9.x and select from the X-Plane menu
Settings – Joystick, Keys & Equipment.
Basically, assigning keys, buttons, knobs, sliders etc. is
very similar to Microsoft Flight Simulator. The only
difference is the way it is created and organized.
The Axis tab allows you to assign Multi Switch panel
sliders to an X-Plane function. Perform the following
steps:
- Slider S1 on the VRinsight panel is moved up and
down. On the X-System window this is the 3
bar from the top.
- Click on the text left of the red bar.
- A pull-down list appears. Select one of your choices.
Here we selected pitch.
- After you selected pitch, the red bar becomes green
and shows pitch left of it, indicating this is assigned
to the pitch channel on your Multi Switch panel.
Assignment Procedures
rd
LH red
Version: 1.00 | November 8, 2010
