Assigning Multi Switch panel pushbuttons goes in the
same way however, for this we need the Buttons:Basic
tab.
As an example we assign Multi Switch panel switch T3
to the GEAR UP/DOWN command.
- If not yet done, select the Buttons: Basic tab.
- Toggle Multi Switch panel switch T3 to DN. The X-
System shows in the LH upper corner 15 (or another
value).
- Click the circle next of the Landing gear down text.
- The assignment of the GEAR DN command is done.
See the output on the screenshot below.
- Do the same with the Multi Switch panel switch T3 to
UP. This should give you in the LH upper corner value
14 or another value.
- Click the circle next of the Landing gear up text.
- The assignment of the GEAR UP command is done.
- Perform the previous steps and apply this to all
buttons, switches, rotary knobs, encoders and
sliders. Additional assignment information can be
found in the X-Plane User Manual.
