Modifying FS9.CFG (FS2004)

FS9 key/command assignments are very similar to that of FSX however; assignment changes
are not made in the standard.xml file, but in FS9.CFG.
- For Windows Vista/7 users:
Go to "X":\Users\<your_name>\AppData\Roaming\Microsoft\FS9.
Note: Since "AppData\Roaming" is a hidden directory, you need to type the whole
directory path. Instead of <your_user> you put your own name e.g.
"X":\Users\Angelique\AppData\Roaming\Microsoft\FS9 where ""X" should be
replaced by the FSX drive letter.
- For Windows XP users:
Go to "X":\Documents and Settings\<your_name>\Application Data\Microsoft\FS9.
Note: Since "Application Data\" is a hidden directory, you need to type the whole
directory path and instead of <your_user> you put your own name.
- Your own fs9.cfg file offers, with the usb pad connected, the following entry:
[JOYSTICK_MAIN {DEAAC6B0-E5A6-11DF-8001-444553540000}].
Note: All the characters between {xxxxxx xxxx etc} will differ on your PC.
- Where you need to look for is the [JOYSTICK_MAIN xxxx] section.
- Find here an example of a fs9.cfg file:
AXIS_EVENT_00=AXIS_AILERONS_SET
AXIS_SCALE_00=64
AXIS_NULL_00=36
AXIS_EVENT_01=AXIS_ELEVATOR_SET
AXIS_SCALE_01=64
AXIS_NULL_01=36
AXIS_EVENT_02=AXIS_THROTTLE_SET
AXIS_SCALE_02=127
AXIS_NULL_02=1
AXIS_EVENT_03=AXIS_RUDDER_SET
AXIS_SCALE_03=64
AXIS_NULL_03=36
AXIS_EVENT_05=AXIS_RUDDER_SET
AXIS_SCALE_05=64
AXIS_NULL_05=36
BUTTON_DOWN_EVENT_00=BRAKES
BUTTON_DOWN_REPEAT_00=1
BUTTON_DOWN_EVENT_01=VIEW_MODE
BUTTON_DOWN_EVENT_02=ELEV_TRIM_DN
BUTTON_DOWN_REPEAT_02=1
BUTTON_DOWN_EVENT_03=ELEV_TRIM_UP
BUTTON_DOWN_REPEAT_03=1
BUTTON_DOWN_EVENT_06=KNEEBOARD_VIEW
BUTTON_DOWN_EVENT_07=GEAR_TOGGLE
BUTTON_DOWN_EVENT_08=VIEW_MODE
BUTTON_DOWN_EVENT_09=GEAR_TOGGLE
BUTTON_DOWN_EVENT_14=FLAPS_DECR
BUTTON_DOWN_EVENT_15=FLAPS_INCR
POV_MOVE_EVENT_00=PAN_VIEW
POV_MOVE_REPEAT_00=1
Find right below an extraction from my own FS9.CFG related to this particular section.
The "AXIS" refers to sliders when it comes to the Multi Switch panel and "BUTTON"
items to for example the pushbuttons.
