Multi Switch Panel
These two images of the Multi Switch Panel show you the identification of the used push
buttons, switches, knobs, encoders and sliders.
B
F
A Fast Rotate and Hold feature for rotary encoders "D"
B Pushbuttons (12)
C Encoder switches (6)
D Potentiometers (2)
E Four positions view button (1)
F Two positions ON-OFF toggle switches (2)
G Return toggle switch (1)
H three positions ON-OFF toggle switch (1)
J Sliders (4)
