INSTALLATION & OPERATING
INSTRUCTIONS
MH36A
MH39A
MH42A

WOODBURNING FIREPLACE

FOR MANUFACTURED HOUSING
Note:
An arrow ( ) found in the text signifies change in content.
WARNING!
Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage. Refer to this
manual. For assistance or additional information, consult a qualified installer, service agency or the gas supplier.
08/04
17804 Rev i
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MH36A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Heatilator MH36A

Summary of Contents for Heatilator MH36A

  • Page 1: Woodburning Fireplace

    INSTALLATION & OPERATING INSTRUCTIONS MH36A MH39A MH42A WOODBURNING FIREPLACE FOR MANUFACTURED HOUSING Note: An arrow ( ) found in the text signifies change in content. WARNING! Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage. Refer to this manual.

  • Page 2: Table Of Contents

    MH SERIES INSTALLATION INSTRUCTIONS TABLE OF CONTENTS Safety Precautions ............................2 Design and Installation Considerations ....................... 3 A. Listings and Code Approvals ........................4 B. Description of the Fireplace System ......................4 C. System Components ........................... 5 D. Pre-Installation Preparation ......................... 9 E.

  • Page 3: Design And Installation Considerations

    MH SERIES INSTALLATION INSTRUCTIONS DESIGN AND INSTALLATION CONSIDERATIONS When selecting a location for your woodburning fireplace, it is important to evaluate a number of considerations. Modern construction techniques can create conditions that may not allow your chimney to draft properly. This may result in smoke spillage from your fireplace, as well as cause other combustion appliances to operate incorrectly.

  • Page 4: Listings And Code Approvals

    United States as described inspections. If you need assistance during installation, in this manual. please contact your local dealer or the Heatilator Technical Services Department, Hearth Technologies Inc., 1915 W. This fireplace has been tested and listed for use with the Saunders St., Mt.

  • Page 5: System Components

    MH SERIES INSTALLATION INSTRUCTIONS C. SYSTEM COMPONENTS 1. Fireplace Components Catalog # Description: MH36A MH39A MH42A Fireplace, includes Integral Grate, Hearth Protection Strips, and Outside Air Kit Hearth Extension DM1036 DM1039 DM1042 Original Bifold Glass Doors - Black Finish DM1036B...
  • Page 6 MH SERIES INSTALLATION INSTRUCTIONS Cat # MH36A 36 in. 41 in. 25-1/4 in. 12-5/8 in. MH39A 39 in. 44 in. 28-1/4 in. 14-1/8 in. MH42A 42 in. 47 in. 31-1/4 in. 15-5/8 in. Fireplace Dimensions 2. Chimney Components The following pictures show only those chimney components which may be safely used with this fireplace.
  • Page 7 MH SERIES INSTALLATION INSTRUCTIONS MH842 - Roof Thimble & Flashing MH841 TR344 CAK4A Round Termination Cap Chimney Air Kit with Storm Collar JB877 CB876 Joint Band Chimney Bracket Offset/Return 08/04 17804 Rev i...
  • Page 8 MH SERIES INSTALLATION INSTRUCTIONS Chimney Sections Catalog # SL306 6 in. 4-3/4 in. SL312 12 in. 10-3/4 in. SL318 18 in. 16-3/4 in. SL3 - Chimney Stabilizer SL324 24 in. 22-3/4 in. SL336 36 in. 34-3/4 in. SL348 48 in. 46-3/4 in.

  • Page 9: Pre-Installation Preparation

    MH42A 48 in. Figure 3 Installation Along a Wall These are rough framing dimensions only. With Outside Air Cat. # MH36A 42 in. 72-3/4 in. 36-3/8 in. 15-5/8 in. 51-3/8 in. MH39A 45 in. 75-3/4 in. 37-7/8 in. 6-5/8 in.
  • Page 10 MH SERIES INSTALLATION INSTRUCTIONS The fireplace must be secured to the manufactured housing structure to prevent the fireplace from shifting during transportation. Do this by nailing through the nailing flanges provided on the sides of the fireplace. 2. Frame the Fireplace 4 in.

  • Page 11: Chimney Requirements

    MH SERIES INSTALLATION INSTRUCTIONS 3. Sidewalls/Surrounds Adjacent combustible side walls must be located a minimum of 12 in. from the fireplace opening. See Figure 6. If you are using a decorative surround constructed of combustible material, it must be located within the shaded area defined in Figure 6.
  • Page 12 MH SERIES INSTALLATION INSTRUCTIONS 1. Using Offsets and Returns To bypass any overhead obstructions, the chimney may be offset using a 15-deg (SL315) or 30-deg (SL330) offset/return. Perform the following steps to determine the correct chimney component combination for your particular installation.
  • Page 13 MH SERIES INSTALLATION INSTRUCTIONS 2. Chimney Height Requirements (above roof line) Major building codes specify a minimum chimney height above the roof top. These specifications are summarized in what is known as the Ten Foot Rule. This rule states: “If the horizontal distance from the side of the chimney to the peak of the roof is 10 ft or less, the top of the chimney must be at least 2 ft above the peak of the roof, but never less than 3 ft in overall...

  • Page 14: Fireplace Installation

    MH SERIES INSTALLATION INSTRUCTIONS F. FIREPLACE INSTALLATION WARNING! Before starting, do the following: 1. Wear gloves and safety glasses for protection. 2. Keep hand tools in good condition. Sharpen cutting edges and make sure tool handles are secure. 3. Always maintain the minimum air space required to the enclosure to prevent fire. 1.
  • Page 15 MH SERIES INSTALLATION INSTRUCTIONS 4. Assemble the Chimney Sections Attach either a straight chimney section or an offset to the top of the fireplace (depending on your installation requirement). Chimney sections are locked together by pushing downward until the top section meets the stop bead on the lower section.
  • Page 16 MH SERIES INSTALLATION INSTRUCTIONS 6. Attic Insulation Shield 8. Secure the Chimney System An insulation shield should be installed when there When offsets and returns are joined to straight pipe is a possibility of insulation coming into contact with sections, they must be locked into position with the the factory built chimney system.
  • Page 17 MH SERIES INSTALLATION INSTRUCTIONS 9. Install the MH842 Ceiling/Roof Thimble See Figures 14 and 15. Locate the point where the chimney will exit the roof by plumbing down to the center of the chimney. Lay out, cut and frame a 14-1/2 in. square opening (measured on the horizontal) through the ceiling and roof structure.
  • Page 18 MH SERIES INSTALLATION INSTRUCTIONS WARNING! WARNING! Do not pack insulation in spaces between the two shields or above This fireplace has not been tested for the shield inside the flashing. This may affect temperatures to ad- use with a chase above the roof. To jacent combustibles.
  • Page 19 MH SERIES INSTALLATION INSTRUCTIONS 12. Complete the Enclosure Complete the fireplace enclosure, allowing space for outside air ducts and gas piping if desired. Electrical wiring should not come in contact with the fireplace. A minimum clearance of 1/2 in. must be maintained between the fireplace sides and the enclosure as well as the fireplace back and the enclosure.
  • Page 20 MH SERIES INSTALLATION INSTRUCTIONS 14. Hearth Extension A hearth extension must be installed with all fireplaces to protect the combustible floor in front of the fireplace from both radiant heat and sparks. The construction of, and materials used for a hearth extension are shown in Figures 19 and 20. A hearth extension of this construction may be covered with any noncombustible decorative material and may have a maximum thickness as per the illustration.
  • Page 21 MH SERIES INSTALLATION INSTRUCTIONS 15. Position the Hearth Extension 16. Finishing Material Position and secure the hearth extension over the Do not install combustible materials over the black protective metal strips that have been placed partially face of the fireplace! This poses a safety hazard under the fireplace front.

  • Page 22: Operating Instructions

    MH SERIES INSTALLATION INSTRUCTIONS G. OPERATING INSTRUCTIONS Note: Save and pass this instruction manual to subsequent home owners. The information provided is intended to notify and warn them about making unsafe future modifications such as the addition of shelves or the use of unauthorized parts and repairs. 1.
  • Page 23 MH SERIES INSTALLATION INSTRUCTIONS 4. Glass Doors 7. Wood Fuel Most efficient fireplace operation using glass doors FIREWOOD: Your fireplace performance depends on is with the doors open. When the doors are open, the the quality of the firewood you use. All seasoned wood, screen must be closed.
  • Page 24 MH SERIES INSTALLATION INSTRUCTIONS SEASONING: Seasoned firewood is nothing more than Note: The first three or four fires should be of mod- wood that is cut to size, split and air dried to a moisture erate size to allow the oils and binders to be burned content of around 20%.
  • Page 25 MH SERIES INSTALLATION INSTRUCTIONS Flue draft is measured as negative pressure in the If the fire is hard to start and smoke spills out of the chimney. The amount of negative pressure determines fireplace, or you find it difficult to establish and maintain how strong the draft is.

  • Page 26: Maintenance Instructions

    MH SERIES INSTALLATION INSTRUCTIONS H. MAINTENANCE INSTRUCTIONS 1. Disposal of Ashes Ashes should be placed in a metal container with a WARNING! tight-fitting lid. The closed container of ashes should A chimney fire can permanently damage your be placed on a noncombustible floor or on the ground, chimney system.

  • Page 27: Index

    MH SERIES INSTALLATION INSTRUCTIONS INDEX Enclosure 19 Outside Air 22 Locations 9 Outside Air Kit 5, 18 Air Clearance 16, 19 Fireplace Installation 14 Overhead Obstructions 12 Air Kit 5, 18 Firescreen 23 Air Kit Handle Location 18 Firestop Spacer 8 Ashes, Disposal of 26 Installation 15 Positioning 14...

  • Page 28: Warranty

    Obtain HHT’s consent to any warranty work before the work is done. ADDITIONAL INFORMATION: If you would like information on current HEATILATOR products or want to locate a dealer in your area, call 1-800-927-6841. 2003 Heatilator is a Registered Trademark of Hearth & Home Technologies Inc.
