Model:
ADI-ZC-FB
READ THIS MANUAL BEFORE INSTALLING OR
OPERATING THIS APPLIANCE. THIS INSTALLERS
GUIDE MUST BE LEFT WITH APPLIANCE FOR
FUTURE REFERENCE.
WARNING: IF THE INFORMATION
IN THESE INSTRUCTIONS IS NOT
FOLLOWED EXACTLY, A FIRE OR
EXPLOSION MAY RESULT CAUS-
ING PROPERTY DAMAGE, PER-
SONAL INJURY, OR DEATH.
- Do not store or use gasoline or other flam-
mable vapors and liquids in the vicinity of this
or any other appliance.
-
What to do if you smell gas
• Do not try to light any appliance.
• Do not touch any electrical switch.
• Do not use any phone in your building.
• Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call
the fire department.
- Installation and service must be performed by a
qualified installer, service agency, or the gas
supplier.
Printed in U.S.A. Copyright 2005
Heatilator, a brand of Hearth & Home Technologies
1915 W. Saunders St., Mt. Pleasant, IA 52641
This product may be covered by one or more of the following patents: (United States) 4593510, 4686807, 4766876, 4793322, 4811534, 5000162, 5016609, 5076254, 5113843, 5191877, 5218953, 5263471,
5328356, 5341794, 5347983, 5429495, 5452708, 5542407, 5601073, 5613487, 5647340, 5688568, 5762062, 5775408, 5890485, 5931661, 5941237, 5947112, 5996575, 6006743, 6019099, 6048195, 6053165,
6145502, 6170481, 6237588, 6296474, 6374822, 6413079, 6439226, 6484712, 6543698, 6550687, 6601579, 6672860, 6688302B2, 6715724B2, 6729551, 6736133, 6748940, 6748942, D320652, D445174,
D462436; (Canada) 1297749, 2195264, 2225408; or other U.S. and foreign patents pending.
WARNING: IMPROPER INSTALLA-
TION, ADJUSTMENT, ALTERATION,
SERVICE OR MAINTENANCE CAN
CAUSE INJURY OR PROPERTY DAM-
AGE. REFER TO THIS MANUAL. FOR
ASSISTANCE OR ADDITIONAL INFOR-
MATION CONSULT A QUALIFIED IN-
STALLER, SERVICE AGENCY, OR THE
GAS SUPPLIER.
1. This appliance may be installed in an af-
2. This appliance is only for use with the type
Please contact your Heatilator dealer with any
questions or concerns. For the number of your nearest
Heatilator dealer, please call 1-800-927-6841.
Heatilator • ADI-ZC-FB • 2032-900 Rev. E • 8/05
Installers Guide
termarket, permanently located, manufac-
tured (mobile) home, where not prohibited
by local codes.
of gas indicated on the rating plate. This
appliance is not convertible for use with
other gases, unless a certified kit is used.
In the Commonwealth of Massachusetts:
• installation must be performed by a licensed
plumber or gas fitter;
• a CO detector shall be installed in the room
where the appliance is installed.
Underwriters
Laboratories Listed
1
Advertisement
Table of Contents
Troubleshooting
Related Manuals for Heatilator ADI-ZC-FB
Summary of Contents for Heatilator ADI-ZC-FB
- Page 1 6145502, 6170481, 6237588, 6296474, 6374822, 6413079, 6439226, 6484712, 6543698, 6550687, 6601579, 6672860, 6688302B2, 6715724B2, 6729551, 6736133, 6748940, 6748942, D320652, D445174, D462436; (Canada) 1297749, 2195264, 2225408; or other U.S. and foreign patents pending. Heatilator • ADI-ZC-FB • 2032-900 Rev. E • 8/05...
-
Page 2: Safety And Warning Information
DO NOT place furniture or any other combustible Young children should be CAREFULLY SUPERVISED household objects within 36 inches of the fireplace when they are in the same room as the appliance. front. Heatilator • ADI-ZC-FB • 2032-900 Rev. E • 8/05... -
Page 3: Table Of Contents
Lighting Instructions ............18 After the Installation ..............18 Section 4: Maintaining and Servicing Your Appliance ..19 Section 5: Troubleshooting ............ 20 Limited Lifetime Warranty ............22 = Contains updated information. Heatilator • ADI-ZC-FB • 2032-900 Rev. E • 8/05... -
Page 4: Section 1: Approvals And Codes
National Electric Code ANSI/NFPA No. 70 (in the United States), or to the CSA C22.1 Canadian Electric Code (in Canada). These models may be installed in a bedroom or bed-sitting room in the U.S.A. and Canada. Heatilator • ADI-ZC-FB • 2032-900 Rev. E • 8/05... -
Page 5: Section 2: Getting Started
The original fireplace may never be returned to solid fuel in this condition. Heatilator • ADI-ZC-FB • 2032-900 Rev. E • 8/05... -
Page 6: Insert Dimensions
* NOTE: If exhaust collar on insert and fireplace damper do not line up, add 4 inches (102mm) to minimum fireplace height for bends in vent pipe. Figure 1. Diagram of insert and minimum fireplace dimensions Heatilator • ADI-ZC-FB • 2032-900 Rev. E • 8/05... -
Page 7: Section 3: Installing The Insert
50 feet. These dimensions are measured from the starting collars of the unit to the end of the last section of vent pipe. See dimension V in Figure 3. Heatilator • ADI-ZC-FB • 2032-900 Rev. E • 8/05... - Page 8 14/12 to 16/12 building. over 16/12 to 18/12 over 18/12 to 20/12 over 20/12 to 21/12 Figure 2. Minimum Height from Roof to Lowest Discharge Opening Heatilator • ADI-ZC-FB • 2032-900 Rev. E • 8/05...
- Page 9 INLET AIR COLLAR OF THE TERMINATION CAP OR TERMINATED IN THE CHIMNEY. A 3 FOOT SECTION OF STAINLESS STEEL FLEXIBLE LINER MUST BE ATTACHED DIRECTLY TO THE EXHAUST COLLAR ON COLLAR SLIDE PLATE. Heatilator • ADI-ZC-FB • 2032-900 Rev. E • 8/05...
- Page 10 (For Flashing Class-A Pipe) SLIDING PLATE CLASS A WOOD PIPE INLET AIR VENT PIPE 3 INCH STAINLESS STEEL COLLAR ADAPTER FOR EXHAUST (MUST BE INSTALLED) Figure 4. Typical configuration of vent liners. Heatilator • ADI-ZC-FB • 2032-900 Rev. E • 8/05...
-
Page 11: Step 2 Positioning, Leveling, And Securing The Insert
CONNECTED TO A CONTROL VALVE IN A TO CHECK FOR GAS LEAKS. MILLIVOLT SYSTEM. STANDING PILOT CONTROLS FLEXIBLE GAS LINE SHUT-OFF Figure 6. Gas Supply Line Figure 5. Gas Controls System Heatilator • ADI-ZC-FB • 2032-900 Rev. E • 8/05... -
Page 12: Step 5 Gas Pressure Requirements
CAN CAUSE IMPROPER AND DANGEROUS OPERATION. VERIFY PROPER OPERATION AFTER SERVICING. THERMOCOUPLE THERMOPILE ROCKER SWITCH RED T1 VALVE WHITE T2 OPTIONAL WALL SWITCH THERMOSTAT OR REMOTE Figure 7. Standing Pilot Ignition Wiring Diagram Heatilator • ADI-ZC-FB • 2032-900 Rev. E • 8/05... -
Page 13: Wiring The Fan
NOTE: If any of the original wire as supplied with the appli- ance must be replaced, it must be replaced with type 105 crated wire. 110-120 VAC Figure 9. Fan Wiring Diagram NOTE: Do NOT install blower if using operable glass doors. Heatilator • ADI-ZC-FB • 2032-900 Rev. E • 8/05... -
Page 14: Step 7 Installing Logs And Ember Material
ON/OFF switch ON/OFF through the hole at the upper SWITCH right corner of the surround - it will be retained in the hole. SURROUND WITH TRIM Figure 13. Heatilator • ADI-ZC-FB • 2032-900 Rev. E • 8/05... -
Page 15: Step 9 Before Lighting The Appliance
8 hours. This will help to cure the products bustible projections above the gas fireplace. used in the paint and logs. Heatilator • ADI-ZC-FB • 2032-900 Rev. E • 8/05... -
Page 16: Step 10 Lighting The Appliance
This will help avoid setting off smoke detectors, and help eliminate LEAVE THIS INSTALLATION MANUAL WITH THE any odors associated with the fireplace’s initial burning. APPLIANCE FOR FUTURE REFERENCE. Heatilator • ADI-ZC-FB • 2032-900 Rev. E • 8/05... -
Page 17: Section 4: Maintaining And Servicing Your Appliance
NOTE: DO NOT handle or attempt to clean the door when it is hot and DO NOT use abrasive cleaners. Heatilator • ADI-ZC-FB • 2032-900 Rev. E • 8/05... -
Page 18: Section 5: Troubleshooting
Check the burner orifice for stoppage. Remove stoppage. orifice. e. Wall switch or Follow the corrective action in Symptom and Possible Cause 1.a above. Check wires are defective. the switch and wiring. Replace where defective. Heatilator • ADI-ZC-FB • 2032-900 Rev. E • 8/05... -
Page 19: Troubleshooting
Ensure that no debris has been placed at the base of, or in the area of the air holes in the center of the base pan beneath the burner. Ensure that the glass is tightened properly on the unit, particularly on top corners. Heatilator • ADI-ZC-FB • 2032-900 Rev. E • 8/05... -
Page 20: Limited Lifetime Warranty
If the Heatilator Appliance is found to be defective in either material or workmanship within one year of the date of original installation, HHT will provide replacement parts at no charge and pay reasonable labor and freight costs, and is for the period of one year following the date of original installation of the Appliance.
