14.3.6 Misfeed at the Paper Separating Section.................................................. 125
14.3.7 Misfeed at the Fusing/Exit Section............................................................ 126
14.3.8 Misfeed at the Document Take-up Section
(When the optional Automatic Document Feeder DF-502 is mounted)127
14.3.9 Misfeed at the Document Transport Section
(When the optional Automatic Document Feeder DF-502 is mounted)128
14.3.10 Misfeed at the Document Exit Section
(When the optional Automatic Document Feeder DF-502 is mounted)129
15. Malfunction code ................................................................................................. 130
15.1 Trouble code ..................................................................................................... 130
15.1.1 Trouble code list ........................................................................................ 130
15.2 How to reset...................................................................................................... 134
15.3 Solution............................................................................................................. 135
15.3.1 C0000: Main Motor malfunction ................................................................ 135
15.3.2 C0044: ADF Cooling Fan Failure
(When the optional Duplexing Document Feeder DF-605 is mounted)136
15.3.3 C0045: Fusing Cooling Fan Motor Malfunction......................................... 137
15.3.4 C004E: Power Supply Cooling Fan Motor Malfunction ............................. 138
15.3.5 C0070: Toner Replenishing Motor Malfunction ......................................... 139
15.3.6 C0210: Abnormal Image Transfer Voltage ................................................ 140
15.3.7 C0500: Warm-up Failure ........................................................................... 141
15.3.8 C0501: Warm-up Failure 2 (ineo 210 Only) .............................................. 141
15.3.9 C0510: Fusing Failure (Abnormally Low Fusing Temperature) ................. 141
15.3.10 C0511: Fusing Failure (Abnormally Low Fusing Temperature 2)
(ineo 210 Only)141
15.3.11 C0520: Fusing Failure (Abnormally High Fusing Temperature) ................ 141
15.3.12 C0521: Fusing Failure (Abnormally High Fusing Temperature 2)
(ineo 210 Only)141
15.3.13 C0650: Faulty Scanner Home Position Sensor......................................... 144
15.3.14 C0F32: Faulty ATDC Sensor ..................................................................... 145
15.3.15 C0F33: Improperly Adjusted ATDC Sensor .............................................. 145
15.3.16 C1038: Engine Connection Failure ........................................................... 146
15.3.17 C1200: Faulty ASIC/Memory .................................................................... 147
15.3.18 C1300: Polygon Motor Malfunction ........................................................... 148
15.3.19 C13F0: Faulty HSYNC .............................................................................. 148
15.3.20 C133B: Communication with Option Error ................................................ 149
15.3.21 C133D: ROM Check Error ........................................................................ 149
15.3.22 C1468: Faulty Parameter Chip.................................................................. 149
15.3.23 C14A3: IR Fluorescent Lamp Fault........................................................... 150
