Owner's Manual
Questions?
Call Us Toll Free
Keys Fitness Helpline
1-888-340-0482
Model Name : ST-NBB
Manufactured Date :
PO # :
Model Name Decal Location
215-00092
09/06 Rev A
ST-NBB

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ST-NBB and is the answer not in the manual?

Questions and answers

Summary of Contents for Keys Fitness ST-NBB

  • Page 1 Owner’s Manual Questions? Call Us Toll Free Keys Fitness Helpline 1-888-340-0482 Model Name : ST-NBB Manufactured Date : PO # : Model Name Decal Location 215-00092 09/06 Rev A ST-NBB...
  • Page 2: Table Of Contents

    Table of Contents Important Safety Information Assembly Parts List Exploded View Warranty Information...
  • Page 3: Important Safety Information

    Advanced: Complete 3 sets of 12 reps DISCLAIMER: Keys Fitness is not responsible for the misuse of any of its products or for any injury sustained while using any Keys Fitness product. The consumer uses any or all of Keys Fitness Products at their own risk.
  • Page 4: Assembly

    Assembly Assembly Hardware...
  • Page 5 Assembly NOTE: Hand tighten bolts and nylon nuts until machine is fully assembled. STEP 1 Connect the Uprights (#2) & (#12) to the Cross Bar (#01) using four Hex bolts M10X75 (#33) and eight D10 washers (#35), two Reinforcement (#17) and four M10 aircraft Nut (#36). Insert the Crutch (#3) into the Uprights (#2)&(#12) through rect.
  • Page 6 Assembly NOTE: Hand tighten bolts and nylon nuts until machine is fully assembled. STEP 2 Attach the back of the Main Frame (#5) to the Cross Bar (#1) with two bolts M10X75 (#33), four D10 Washers (#35) and two M10 air- craft nuts (#36).
  • Page 7 Assembly NOTE: Hand tighten bolts and nylon nuts until machine is fully assembled. STEP 3 Install the Leg Developer (#7) to bracket of Leg Developer Holder (#11) using one M10X75 Bolt (#32), two D10 Washers (#35), and one M10 aircraft nut (#36), Insert the Roller Foam Tube (#10) halfway into leg developer (#7).
  • Page 8 Assembly NOTE: Hand tighten bolts and nylon nuts until machine is fully assembled. STEP 4 Attach the backrest support (#9) to the pivot on the Main Frame (#5) Align Backrest Pad (#13) to backrest support (#9) and secure with four M6X40 Bolts (#29), and four D6.5 washers (#31). Place the seat pad (#14) on bracket of the Main Frame (#5) and secure with four M6X15 Bolts (#30), and four D6.5 washers (#31).
  • Page 9: Assembly

    Assembly NOTE: Hand tighten bolts and nylon nuts until machine is fully assembled. STEP 5 Attach the two Butterfly Arms (#40) to the Upright Beams (#2)&(#12) with two M10x120 Hex Bolts (#39), two M10 Regular nuts (#37), two D10 spring washers (#38) and two M10 aircraft nuts (#36).
  • Page 10: Parts List

    ST-NBB Parts List Rev A Description CROSS BAR, M-NBB (SILVER) RIGHT UPRIGHT, M-NBB (SILVER) CRUTCH, M-NBB BACKREST ADJ BAR, ST-NBB (NEW GAUGE) MAIN FRAME, M-NBB (SILVER) FRONST BASE FRAME, M-NBB (SILVER) LEG DEVELOPER M-SBA FRONT STAND TUBE, M-NBB (SILVER) BACKREST SUPPORT, M-NBB...
  • Page 11: Exploded View

    Exploded View...
  • Page 12: Customer Service

    To contact us for customer service or replacement parts, call 1-888-340-0482. CUSTOMER SERVICE If you have any questions regarding this or any Keys Fitness product, or if we may be of assistance in any way, please do not hesitate to call our toll free number 1-888-340-0482.
  • Page 13 Keys Fitness Products, L.P. 4009 Distribution Drive, Suite 250 Garland, Texas 75041 Customer Service: 1-888-340-0482...
