Summary of Contents for Keys Fitness Strength Trainer ST-PR
- Page 1 Owner’s Manual Questions? Call Us Toll Free Keys Fitness Helpline 1-888-340-0482 Model Name : ST-PR Manufactured Date : PO # : Model Name Decal Location 215-00090 08/06 Rev B ST-PR...
-
Page 2: Table Of Contents
Table of Contents Important Safety Information Assembly Parts List Exploded View Warranty Information 4-11... -
Page 3: Important Safety Information
Advanced: Complete 3 sets of 12 reps DISCLAIMER: Keys Fitness is not responsible for the misuse of any of its products or for any injury sustained while using any Keys Fitness product. The consumer uses any or all of Keys Fitness Products at their own risk. -
Page 4: Assembly
Assembly Assembly Hardware... - Page 5 Assembly NOTE: Hand tighten bolts and nylon nuts until machine is fully assembled. STEP 1 Connect the Left and Right Stabilizer (#1) & (#2) by a Rear Stabilizer (#3). Align the holes and secure themwith one 6 ¼”x 2”Bracket (#41), two M10 x 90 Carriage Bolts (#37), Washers Dia10 (#39), and M10 Aircraft Nuts (#38) at each end of the Rear Stabilizer.
- Page 6 Assembly NOTE: Hand tighten bolts and nylon nuts until machine is fully assembled. STEP 2 Attach the Left Support (#6) onto the Left Stabilizer (#1). Secure it with one 4 ¾”x 2” Bracket (#42), two M10 x 70 Carriage Bolts (#36), Washers Dia10 (#39), and M10 Aircraft Nuts (#38) from the bottom up.
- Page 7 Assembly NOTE: Hand tighten bolts and nylon nuts until machine is fully assembled. STEP 2 Cont. Attach the bottomof Vertical Frame (#8) to the bracket on the Rear Stabilizer (#3). Secure the Vertical Frame to the Rear Stabilizer with two M10 x 20 Hex Bolts (#35) and Washers Dia10 (#39).
- Page 8 Assembly NOTE: Hand tighten bolts and nylon nuts until machine is fully assembled. STEP 3 Slide the Sliding Weight Holder (#10) onto the Vertical Frame (#8). Attach two Spring Clips 1”(#31) to the posts on the Sliding Weight Holder. Insert the Upper Frame (#9) onto the top opening on the Vertical Frame (#8). Align the bottomhole on the top of the Vertical Frame.
- Page 9 Assembly NOTE: Hand tighten bolts and nylon nuts until machine is fully assembled. STEP 4 Notice: The cable diagram below shows the proper routings of the 110”Lat Cable (#20), the 92” Low Row Cable (#16) for the cable assembly in Steps 4 Use the diagram to be sure that the two cables have been assembled correctly.
- Page 10 Assembly NOTE: Hand tighten bolts and nylon nuts until machine is fully assembled. STEP 4 Cont.
-
Page 11: Assembly
Assembly NOTE: Hand tighten bolts and nylon nuts until machine is fully assembled. STEP 5 Attach two Weight Plate Holders (#13) to the holes on the side of each Left and Right Supports (#6) &(#7). Secure each with a M10 x 20 Hex Bolt (#35) and Washer Dia10 (#39). -
Page 12: Parts List
Parts List Ref # Part # 223-00861 223-00862 223-00863 223-00864 223-00865 223-00866 223-00867 223-00868 223-00869 219-00340 223-00400 210-00168 219-00291 210-00101 223-00401 229-00058 223-00402 206-00220 210-00169 229-00059 206-00154 206-00155 206-00156 206-00157 206-00158 219-00292 206-00065 206-00160 206-00161 210-00102 210-00103 206-00162 206-00163 202-00164 202-00296 202-00166 202-00418... -
Page 13: Exploded View
Exploded View... -
Page 14: Customer Service
To contact us for customer service or replacement parts, call 1-888-340-0482. CUSTOMER SERVICE If you have any questions regarding this or any Keys Fitness product, or if we may be of assistance in any way, please do not hesitate to call our toll free number 1-888-340-0482. - Page 15 Keys Fitness Products, L.P. 4009 Distribution Drive, Suite 250 Garland, Texas 75041 Customer Service: 1-888-340-0482...
