Owner's Manual
Questions?
Call Us Toll Free
Keys Fitness Helpline
1-888-340-0482
Model Name : ST-DFIDL
Manufactured Date :
PO # :
Model Name Decal Location
215-00081
08/06 Rev A
ST-DFIDL

Advertisement

loading
Need help?

Need help?

Do you have a question about the STRENGTH TRAINER ST-DFIDL and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Keys Fitness STRENGTH TRAINER ST-DFIDL

  • Page 1 Owner’s Manual Questions? Call Us Toll Free Keys Fitness Helpline 1-888-340-0482 Model Name : ST-DFIDL Manufactured Date : PO # : Model Name Decal Location 215-00081 08/06 Rev A ST-DFIDL...
  • Page 2: Table Of Contents

    Table of Contents Important Safety Information Assembly Parts List Exploded View Warranty Information 4-11...
  • Page 3: Important Safety Information

    Advanced: Complete 3 sets of 12 reps DISCLAIMER: Keys Fitness is not responsible for the misuse of any of its products or for any injury sustained while using any Keys Fitness product. The consumer uses any or all of Keys Fitness Products at their own risk.
  • Page 4: Assembly

    Assembly Assembly Hardware...
  • Page 5 Assembly NOTE: Hand tighten bolts and nylon nuts until machine is fully assembled. STEP 1 Attach the Main Frame (#1) to the Front Stabilizer (#2). Align the holes and secure it with three M10×5/8" Allen Bolts (#31) and three 3/4" Washers (#39). Attach the Main Frame (#1) to the Rear Stabilizer (#3).
  • Page 6 Assembly NOTE: Hand tighten bolts and nylon nuts until machine is fully assembled. DIAGRAM 2 STEP 2 Attach two Bushings (#23) to each Seat Support Frames (#6). Attach one Backrest Support (#7) to the Seat Support Frame (#6). Align the holes and secure them with one M10×1 5/8"...
  • Page 7 Assembly NOTE: Hand tighten bolts and nylon nuts until machine is fully assembled. DIAGRAM 3 STEP 3 Align the holes on the two Backrest Supports (#7) to the pivot on the Sliding Block (#9). Secure them with one M10×6 1/4" Allen Bolt (#35), two 3/4" Washers (#39) and one M10 Nylon Nut (#41).
  • Page 8 Assembly NOTE: Hand tighten bolts and nylon nuts until machine is fully assembled. DIAGRAM 4 STEP 4 Attach the Seat Incline Support Bracket (#8) to the Main Frame (#1). Secure it with one M10×4 3/4" Allen Bolt (#34), two 3/4" Washers (#39) and one M10 Nylon Nut (#41).
  • Page 9 Assembly NOTE: Hand tighten bolts and nylon nuts until machine is fully assembled. DIAGRAM 5 STEP 5 Place the Seat Pad (#14) onto the Seat Support Frames (#6). Align the holes and secure it with four M8×2" Allen Bolts (#37) and four 5/8"...
  • Page 10 Assembly NOTE: Hand tighten bolts and nylon nuts until machine is fully assembled. DIAGRAM 6 STEP 6 Insert the Arm Curl Stand (#17) into the top opening in front of the Seat. Secure it with a Knob Lock (#20) underneath the Seat. Attach the Arm Curl Pad (#21) to the Arm Curl Stand (#17).
  • Page 11: Assembly

    Assembly NOTE: Hand tighten bolts and nylon nuts until machine is fully assembled. DIAGRAM 6 STEP 6 cont. Insert one 17" Long Foam Roll Tube (#11) halfway through the holes on front of the Main Frame (#1). Insert two 16" Foam Roll Tubes (#43) halfway through the holes on the Leg Developer (#5).
  • Page 12: Parts List

    Parts List Ref # Part # 223-00801 223-00802 219-00299 219-00300 223-00833 219-00301 223-00416 210-00109 210-00110 223-00417 219-00302 206-00170 210-00111 228-00171 228-00172 202-00183 223-00800 206-00171 210-00103 210-00112 228-00173 206-00172 202-00184 206-00173 206-00235 210-00038 202-00596 206-00174 206-00370 206-00371 202-00185 202-00186 202-00187 202-00188 202-00189 202-00190 202-00191...
  • Page 13: Exploded View

    Exploded View...
  • Page 14: Customer Service

    To contact us for customer service or replacement parts, call 1-888-340-0482. CUSTOMER SERVICE If you have any questions regarding this or any Keys Fitness product, or if we may be of assistance in any way, please do not hesitate to call our toll free number 1-888-340-0482.
  • Page 15 Keys Fitness Products, L.P. 4009 Distribution Drive, Suite 250 Garland, Texas 75041 Customer Service: 1-888-340-0482...
