Summary of Contents for Dyconn WA540S
- Page 2 Although we try our best, Dyconn makes no claim that the information comprised herein covers all conditions or details in connection with installation or use of this product. Dyconn assumes no responsibility for accuracy or adequacy of information comprised in this document.
- Page 3 This product contains small items; please keep these items away from children. Do not exceed the maximum weight capacity for this product. Exceeding the weight capacity can result in serious personal injury or damage to equipment! Specifications Weight Capacity 17.6lbs (8Kg) Suits LCD Flat Panel Displays 12”(300mm)-24”(610mm)
- Page 4 Supplied Parts Page...
-
Page 5: Assembly And Installation
Required Tools ASSEMBLY and INSTALLATION INSPECT THE MOUNT BEFORE ASSEMBLY 1. Carefully inspect/verify that all components are present. 2. If the mount/components are damaged or missing, please contact the company/seller of the product you purchased this unit from and report the issue. Note: Read all assembly instructions before starting the installation process. - Page 6 Step 【1】 Wood Wall Installation Drilling into electrical wires or cables can cause serious personal injury! Always make certain that the area behind mounting area is free of electrical wires and cables before drilling or installing. Improper installation can lead to the mount falling causing severe personal injury or damage to equipment.
- Page 7 Figure 1-2 Figure 1-3 4. Insert Philips Screw ST6.3x65mm (3) through Washer (14), Wall Plate (2) and finally into pilot hole. Repeat for remaining Philips Screws. Tighten Philips Screw securely (See Figure 1-4). Figure 1-4 Page...
- Page 8 Step 【1】 Concrete Wall Installation Drilling into electrical wires or cables can cause serious personal injury! Always make certain that the area behind mounting area is free of electrical wires and cables before drilling or installing. Improper installation can lead to the mount falling causing severe personal injury or damage to equipment.
- Page 9 Figure 1-6 Figure 1-7 4. Insert Anchor (13) into anchor hole and seat with gentle tapping from hammer. Hammer anchor screw until anchor has fully collapsed against back side of concrete wall (See Figure 1-8). Figure 1-8 Page...
- Page 10 5. Insert Philips Screw ST6.3x65mm (3) through Washer (14), Wall Plate (2) and finally into anchor (13). Repeat for remaining Philips Screws. Tighten Philips Screws securely (See Figure 1-9). Figure 1-9 Page...
- Page 11 Step 【2】 Display Installation Using improper screws or screw size may damage your display. If spacers are required, be sure to use screws of the correct size. Proper screws will easily and completely thread into the display mounting holes. Inadequate thread engagement in the display may cause display to fall.
- Page 12 3. Determine depth of recessed mounting holes relative to the back of the display. 4. Select the proper length of Screws (6, 8) that suit your monitor’s specifications. Place the Spacers (4) on the back of display, follow by positioning the mounting holes in the Tilter Mount Bracket so that the mounting holes on the Tilter Mount Bracket and Spacers (4) are aligned (See Figure 2-2).
- Page 13 Step 【3】 Attaching Wall Mount LCD Arm Assembly Wall Mount LCD Arm will only work when a display is properly installed. Attaching the LCD Arm Assembly 1. Attach the Wall Mount LCD Arm Assembly (1) to Wall Plate (2) by placing the LCD Arm Assembly downward, onto the top of the Wall Plate pole (See Figure 3-1).
- Page 14 3. Place the Cover (11). Insert the Phillips Screw M6x12mm (12) and Plastic Washer (15) and tighten using a Phillips Screwdriver. Do not over tighten. This is to help prevent the LCD Arm Assembly from detaching (See Figure 3-3). Figure 3-3 Page...
- Page 15 Step 【4】 Cable Management Ensure Wall Mount LCD Arm Assembly is fully extended before connecting cables. Exercise caution when attaching or removing the display to avoid personal injury or damage to equipment. Disconnect power before removing the display. Note: Be sure to leave enough slack in the cables to allow for movement of the arms. Installing Cable Management 1.
- Page 16 Step 【5】 Adjusting the Display Monitor Forced movement of Mount Bracket without loosening the Screws will damage Wall Mount LCD Arms Assembly or display monitor. Exercise caution when adjusting the display. Support the display to avoid damage to equipment. Disconnect power before removing the display. Adjusting the Wall Mount LCD Arm Assembly Resistance 1.
- Page 17 Adjusting the Mount Bracket Resistance 2. The product is engineered to control the resistance in the Tilter Mount Bracket to suit your display swivel of +/- 90 degrees, tilt of +/- 90 degrees and also display orientation of +/- 360 degrees. You can easily control the amount of resistance in the Tilter Mount Bracket to suit your display monitor.
- Page 18 Figure 5-3 6. This product is manufactured and designed to adjust quickly and easily according to your needs. To adjust the height, remove the Extension Arm (1) from Wall Plate (2) followed by reattaching the LCD Arm to the Wall Plate (2) to achieve your desired position (See Figure 5-4).
- Page 19 Figure 5-5 Page...
- Page 20 Step 【6】 Ergonomic Guidelines Note: Proper ergonomic design is necessary to prevent repetitive strain injuries, which can develop over time and can lead to long-term disabilities. 1. To ensure the correct focal distance for ultimate visual comfort, a viewing distance between 460mm (18”) to 610mm (24”) is recommended (See Figure6-1).
- Page 21 2. To assess the fit between a person and their work, ergonomists recommended that the optimal screen position should be slightly below eye level. Viewing angle should be approximately 10°-20° downward onto the screen’s center. The lumbar (bottom five vertebrate in the spine) needs to be supported to decrease disc pressure. Sitting in a chair with a backrest that inclines backwards and has adequate lumbar support is critical to prevent excessive lower back pressures.
- Page 22 Dyconn disclaims any liability for modification, improper installations, or installations over specified weight range. Dyconn will not be liable for any damages arising out of the use of, or inability to use of Dyconn products. Warranty specification is subject to change without prior notice.
