- Page 2 Although we try our best, Dyconn makes no claim that the information comprised herein covers all conditions or details in connection with installation or use of this product. Dyconn assumes no responsibility for accuracy or adequacy of information comprised in this document.
- Page 3 Please read the following warning before installing Verify that all parts are included. Do not install if the products or hardware are damaged. Not all hardware included will be used. Please contact a qualified installer. This product contains moving parts. Use with caution. Determine approximate location for mounting and be sure to consider the display size, extension, height adjustment and pitch/roll requirements.
- Page 4 Supplied Parts Page...
-
Page 5: Assembly And Installation
Required Tools ASSEMBLY and INSTALLATION INSPECT THE MOUNT BEFORE ASSEMBLY 1. Carefully inspect/verify that all components are present. 2. If the mount/components are damaged or missing, please contact the company/seller of the product you purchased this unit from and report the issue. Note: Read all assembly instructions before starting the installation process. - Page 6 Step 【1】 Wood Wall Installation Drilling into electrical wires or cables can cause serious personal injury! Always make certain that the area behind mounting area is free of electrical wires and cables before drilling or installing. Improper installation can lead to the mount falling causing severe personal injury or damage to equipment.
- Page 7 Figure 1-3 Figure 1-4 3. Insert Philips Screw ST6.3x65mm (18) through Washer (12), Wall Plate (3) and finally into pilot hole. Repeat for remaining Philips Screws. Tighten Philips Screw securely (See Figure 1-5). Figure 1-5 Page...
- Page 8 Step 【1】 Masonry Wall Installation Drilling into electrical wires or cables can cause serious personal injury! Always make certain that the area behind mounting area is free of electrical wires and cables before drilling or installing. Improper installation can lead to the mount falling causing severe personal injury or damage to equipment.
- Page 9 Figure 1-8 Figure 1-9 4. Insert Anchor (11) into anchor hole and seat with gentle tapping from hammer. Hammer anchor screw until anchor has fully collapsed against back side of concrete wall (See Figure 1-10). Figure 1-10 Page...
- Page 10 5. Insert Philips Screw ST6.3x65mm (18) through Washer (12), Wall Plate (3) and finally into anchor (11). Repeat for remaining Philips Screws. Tighten Philips Screws securely (See Figure 1-11). 6. Attach WA640D (14) to Wall Plate (3) and secure using the Allen Wrench 2.5mm (10) (See Figure 1-12).
- Page 11 Step 【2】 Display Installation Using improper screws or screw size may damage your display. If spacers are required, be sure to use screws of the correct size. Proper screws will easily and completely thread into the display mounting holes. Inadequate thread engagement in the display may cause display to fall.
- Page 12 3. Determine depth of recessed mounting holes relative to the back of the display. 4. Select the proper length of Screws (6, 8) that suit your monitor’s specifications. Place the Spacers (4) on the back of display, follow by positioning the mounting holes in the Tilter Mount Bracket so that the mounting holes on the Tilter Mount Bracket and Spacers (4) are aligned (See Figure 2-2).
- Page 13 Step 【3】 Attaching Articulating Arm Assembly Wall Mount Articulating Arm Assembly will only work when a display is properly installed. Attaching the Articulating Arm Assembly 1. Attach the Articulating Arm (1, 2) Assembly to the WA640D by placing the Articulating Arm Assembly downward onto the WA640D (See Figure 3-1).
- Page 14 3. Place the Cover (17). Insert Phillips Screw M6x12mm (16) and Plastic Washer (15) and tighten using a Phillips Screwdriver. Do not over tighten. This is to help prevent the Articulating Arm Assembly from detaching (See Figure 3-3). Figure 3-3 4.
- Page 15 Step 【4】 Cable Management Ensure Wall Mount Articulating Arm Assembly is fully extended before connecting cables. Exercise caution when attaching or removing the display to avoid personal injury or damage to equipment. Disconnect power before removing the display. Note: Be sure to leave enough slack in the cables to allow for movement of the Arms. Installing Cable Management 1.
- Page 16 Step 【5】 Adjusting the Display Monitor Forced movement of the Wall Mount Articulating Arms Assembly or Mount Bracket without loosening the Screws will damage Articulating Arms Assembly or display monitor. Exercise caution when adjusting the display. Support the display to avoid damage to equipment.
- Page 17 Adjusting the Mount Bracket Resistance 3. The product is engineered to control the resistance in the Tilter Mount Bracket to suit your display swivel of +/- 90 degrees, tilt of +/- 90 degrees and also display orientation of +/- 360 degrees. You can easily control the amount of resistance in the Tilter Mount Bracket to suit your display monitor.
- Page 18 7. This product is manufactured and designed to adjust quickly and easily according to your needs. To adjust the height, remove the Extension Arm from Wall Plate (3) followed by reattaching the LCD Arm to the Wall Plate (3) to achieve your desired position (See Figure 5-5).
- Page 19 Step 【6】 Ergonomic Guidelines Note: Proper ergonomic design is necessary to prevent repetitive strain injuries, which can develop over time and can lead to long-term disabilities. 1. To ensure the correct focal distance for ultimate visual comfort, a viewing distance between 460mm (18”) to 610mm (24”) is recommended (See Figure6-1).
- Page 20 2. To assess the fit between a person and their work, ergonomists recommended that the optimal screen position should be slightly below eye level. Viewing angle should be approximately 10°-20° downward onto the screen’s center. The lumbar (bottom five vertebrate in the spine) needs to be supported to decrease disc pressure. Sitting in a chair with a backrest that inclines backwards and has adequate lumbar support is critical to prevent excessive lower back pressures.
- Page 21 Dyconn disclaims any liability for modification, improper installations, or installations over specified weight range. Dyconn will not be liable for any damages arising out of the use of, or inability to use of Dyconn products. Warranty specification is subject to change without prior notice.
