- Page 1 YPbPr/Composite to HD/SD-SDI Converter AT-AT-HDSDI User Manual http://www.atlona.com/...
-
Page 2: Safety And Notice
The Atlona AT-AV-HDSDI YPbPr/Composite to HD/SD-SDI Converter has been tested for conformance to safety regulations and requirements, and has been certified for international use. However, like all electronic equipments, Atlona AT-AV-HDSDI should be used with care. Please read and follow the safety instructions to protect yourself form possible injury and to minimize the risk of damage to the unit. - Page 3 Introduction The AT-AV-HDSDI provides high quality 12-bit conversion between analog YPbPr and composite inputs and SDI video digital output. The AT-AV-HDSDI supports both SD-SDI and HD-SDI formats (SMPTE 259M, SMPTE 292M, and SMPTE 296M), and also features 3 SMPTE compliant HD/SD-SDI outputs. Features ...
-
Page 4: Package Contents
Package Contents 1x AT-AV-HDSDI 1x 5V 4A power adapter 1x User Manual Technical Specifications Video bandwidth: 300Mbps, 1.485, 1.485/1.001 Gbps Output signal: HD/SD-SDI (SMPTE 259M, SMPTE 292M, SMPTE 296M) Output impedance: 75Ω Input signal: HD/SD YPbPr/Composite ... -
Page 5: Format Specifications
Format Specifications HD INPUT Component Composite SMPTE 296M -1, -2, ○ 720p @60/59.94/50Hz RP-133 ○ 1035i @60/59.94/50Hz SMPTE RP-133 ○ 1080i @60/59.94/50Hz SMPTE RP27.1, RP-133 SD INPUT ○ ○ ○ ○ DIP Switch Color Space Mode YPbPr Color Space (Default) RGB Color Space Sync Mode Internal Sync (Default) -
Page 6: Panel Descriptions
Panel Descriptions Front Panel HD/SD-SDI Output 1 5. HD/SD-SDI Output 3 HD/SD LED 6. IR Receiver** HD/SD-SDI Output 2 7. 5V Power Power indicator LED ** unavailable in AT-AV-HDSDI Rear Panel 8. External sync 9. Y 10. Pb 11. Pr... -
Page 7: Limited Warranty
Atlona or an authorized dealer. Should this product fail to be in good working order within 1 year warranty period, Atlona, at its option, repair or replace the unit, provided that the unit has not been subjected to accident, disaster, abuse or any unauthorized modifications including static discharge and power surges.
