Invacare Spectra Plus Technical Manual page 16

Section Spectra Plus Tech Manual
Dismantling
STEP 1
Remove the motor end via the two Phillips screws.
STEP 2
Remove the two/three electro magnetic brake fixing screws and remove the brake.
STEP 3
Remove the brush feeder wire termination screws, release the brush springs and remove brushes.
To reassemble reverse the step 1 to 4, taking care not to damage the brushes and ensure correct alignment of
the electro-magnetic brake.
Should there be fitting, scoring or wear then replace the Motor Unit.
NOTE:
WHEN REFITTING MOTORS, PLEASE ENSURE THAT BOHT SUPPLY WIRES ARE FASTENED TO THE
CONTROLLER IN SUCH A WAY THAT THE RIGHT HAND MOTOR CANNOT BE ACCIDENTLY
CONNECTED TO THE LEFT AND VISA VERSA.
Page 16 of 78 19/01/2004
