722 User Guide and Technical Information
Input 1/2 Level
11)
When control knobs are adjusted, indi-
cates the gain level in dB for each analog
input gain control. Top display is input
1, bottom display is input 2. Normal mic
input gain range is from 26 dB to 70 dB,
low gain mic range is from 10 dB to 50
dB, line input range is from
dB. "LOCKED" will be displayed on the
LCD when the pot is turned with digital
inputs, and with line inputs with menu
control.
10
firmware v. 2.00
−
6 dB to 18
Features and specifications are subject to change. Visit www.sounddevices.com for the latest documentation.
11
External Digital Clock Indicator
12)
The 722 is locked to a valid external
digital or word clock source when the L
is in the display.
Cue Marker Display (not shown)
In record mode, indicates when cue
markers are set. Markers set by pressing
the record key (option must be selected
in setup menu). In playback mode, dis-
plays cue points numerically as they are
reached in a fi le.
12
