- Page 1 Designed by Alfred Vassilkov Model X Diamond Serial Number...
- Page 2 Your ESTELON loudspeakers have passed our quality control: – Technical test passed. Harry Jürgenson Engineer, Alfred & Partners – Listening test passed. Alfred Vassilkov Head of Research and Development, Alfred & Partners...
-
Page 3: Table Of Contents
1.1. Alfred & Partners ........4 1.2. Estelon Model X Diamond ......6 2. -
Page 4: Intoduction
INTRODUCTION 1.1. Alfred & Partners Alfred & Partners, the Tallinn based design studio and think tank, is not simply a business but a dedication, a dedication to a single, heartfelt idea – the production of Instruments, Sound Diffusers, Sculptures – capable of unveiling the rich, emotional tapestry of music in a personally involving way. - Page 5 – music. ••• For Estelon, the new brand, the visionary development started in 2006 when Alfred started to analyze materials and technologies for producing cabinets with streamlined shapes that could not only reproduce the best sound but also assimilate into an interior, with their elegant “sculpture”...
-
Page 6: Estelon Model X Diamond
The result of a reassessment, a further refinement and extension of the performance goals already in place for the much praised Model XA – Alfred Vassilkov’ s first tribute to the Estelon brand and the birth of a new approach to loudspeaker design. Chief among the physical design elements continues to be the use of the E-lon cabinet form. - Page 7 Cabinet Design – The Estelon X-Diamond continues the inte- gration of the many lessons learned from Alfred Vassilkov’s more than 25 years designing loudspeakers. The E-lon shape – choices of material...
- Page 8 And finally the multiple coats of the lacquer finish is applied – hand sand- ing accompanying each finishing coat. Final polishing – to a mirror-like fin- ish, again, is done by hand. The Estelon’ s X-Diamond is offered in a choice of liquid gloss or matte finishes or the optional premium finishes.
-
Page 9: Specifications
SPECIFICATIONS Woofer: 11“ Accuton, ceramic sandwich dome Mid Woofer: 7“ Accuton, ceramic sandwich dome Tweeter: 1.2“ Accuton, Diamond inverted dome Internal Wiring: Kubala-Sosna Capacitors: Mii, Teflon-Hybrid Inductors: Goertz, copper foil – Air Core Frequency Response: 22 - 45 000 Hz Power Rating: 200 W Min. - Page 10 Dimensions in Millimeters:...
-
Page 11: Unpacking Instructions
3. UNPACKING INSTRUCTIONS Your Estelon loudspeakers come packaged individually in 2 separate flight cases – we strongly recommend keeping these cases for possible future use / transport. Due to the substantial weight and slippery surface of the loudspeakers we suggest that two persons assist in the unpacking and positioning of them for listening. - Page 12 6. At this time, please put on the gloves that you find included in the accessories box. Now, with the speaker upright and out of the flight case, carefully remove the cloth bag from the speaker and roll it to the desired position in your room. We recommend keeping the speakers on wheels during the initial set-up.
- Page 13 Once the final position has been located, it is time to re- place the transport wheels with the enclosed spikes. Doing one side at a time, carefully tilt the speaker to one side and replace the wheels with the enclosed spikes. Please retain the wheels, once removed, in the event that repackaging is required.
-
Page 14: Set-Up
SET-UP 4.1. Initial positioning in the room Model X Diamond – Suggested room size 25-60 m When positioning the speakers in your room, if possible, it is desirable to allow for “free” space around the speakers so as to assist in minimizing sound reflections from walls, furniture etc. -
Page 15: Break-In Period
/ writing on the cable. 4.3. Break-in period Although your Estelon speakers had an initial break-in at the factory, due to shipping conditions – pressure/temperature changes that they may have incurred, the speakers will need to go through an additional break-in process before their final set-up. - Page 16 ate again, until the proper position with a balanced, natural sound is found. We suggest that you test, listen, with different music styles so as to avoid specific accents. When changing the position of your speakers please keep in mind that: •...
-
Page 17: Taking Care Of Your Estelon Speakers
Taking care of your Estelon speakers The multicoated finishes applied to Estelon speakers are con- sidered to be amongst the most advanced automotive finishes avail- able. They are extremely strong and durable. In order to assist you in maintaining their stunning appearance, your Estelon loudspeakers come supplied, from the factory, with special cleaning / polishing cloths. -
Page 18: Warranty - Technical Services
five years from the date of original purchase, subject to the following conditions. Failure to regis- ter the ESTELON product within 30 days from original purchase will result in a warranty period of 90 days from the date of purchase. - Page 19 (available from the factory via phone or email). Upon receipt of defective product, ESTELON agrees to repair the product without charge for parts or labour. The product will then be returned via prepaid, insured freight, with carrier at the sole deter-...
-
Page 20: Specifications
2. Upon clicking the ‘Submit’ button on the Return Authori- zation Form, the ESTELON factory will review it for completeness and return an e-mail to you with an RA number when required (please al- low 2-5 days for a return e-mail). - Page 21 ESTELON factory. BUT under any and all circumstances customers are welcome to contact our sales department, as listed on our web site www.estelon. com, for service assistance. All non warranty repairs are warranted for one year from the date of return shipment.
- Page 22 ESTELON is a trademark of Alfred & Partners OÜ Alfred & Partners OÜ Tanuma 126 13521 Tallinn Estonia Notes...
