- Page 1 EXTREME USER MANUAL EXTREME USER MANUAL...
-
Page 2: Technical Specifications
5 adjustable heights 1770 - 2070 mm (69,7’’-81,5’’) Width: 670 mm (26,4”) Depth: 800 mm (31,5”) Weight (Upper Module): 75 kg (165 lbs) Weight (Lower Module): 175 kg (386 lbs) Net Weight Total: 250 kg per loudspeaker (551 lbs) Suggested room size 50-150 m2. EXTREME USER MANUAL... -
Page 3: Unpacking Instructions
UNPACKING INSTRUCTIONS Your Estelon Extreme loudspeakers come packaged with each module in 4 separate flight cases – we strongly recommend keeping these cases for possible future use / transport. Bring the four flight cases for unpacking as close as possible to the speakers positioning point*. - Page 4 The best listening point: the distance between your ears and the floor should be approx. 1 m (4,2 ft), the distance between the listener and the speakers should be similar to the distance between the two speakers. The recommended speaker’s direction is approximately 5°-7°, off axis, towards the listening position. EXTREME USER MANUAL...
- Page 5 Remove the cloth bag. Remove the top plate (#9). Place the mat (#4) to the cabinet’s top as shown in the drawing using the tape supplied. Please repeat the procedures 1-9 with the second Lower Module. EXTREME USER MANUAL...
- Page 6 1 fig. 2 fig. 3 EXTREME USER MANUAL...
- Page 7 5 fig. 6 top view EXTREME USER MANUAL...
- Page 8 7 fig. 8 fig. 9 EXTREME USER MANUAL...
- Page 9 Slowly, lower the Upper Module until the two cones are (#13) strongly fixed in the grooves (#14). Remove belt # 12. Remove protective matte from the top of the Lower Module. Remove cloth bag from Upper Module. Please repeat procedure 11-21 with the second Upper Module. EXTREME USER MANUAL...
- Page 10 11 fig. 12 fig. 14 EXTREME USER MANUAL...
- Page 11 15 fig. 16 EXTREME USER MANUAL...
- Page 12 17 30 cm fig. 18 EXTREME USER MANUAL...
- Page 13 Typically, the signal flow will be in the same direction as the labelling / writing on the cable. Estelon Extreme can be also bi-amped or bi-wired at your choice. In this case remove wire jumpers to be able to use all connectors. Connect one cable to upper binding posts and another cable to lower binding posts: speaker terminal „+“with the amplifier terminal „+“...
- Page 14 27 fig. 28 EXTREME USER MANUAL...
- Page 15 35 Bottom view, where to connect the feet. EXTREME USER MANUAL...
- Page 16 (it will slide on cart). Estelon Extreme allows you to adjust the speaker height for optimising the sound in regard of audience’s position and room specifics. It has 5 different heights (each step 300 mm).
- Page 17 To avoid any possible influence on the sound we recommend to remove the Controller while using the speakers. For packing follow the same procedures in the opposite direction. If you have any questions, please contact authorised Estelon dealer for assistance. EXTREME USER MANUAL...
- Page 18 Failure to register the ESTELON product within 30 days from original purchase will result in a warranty period of 90 days from the date of purchase.
- Page 19 Upon receipt of defective product, ESTELON agrees to repair the product without charge for parts or labour. The product will then be returned via prepaid, insured freight, with carrier at the sole determination of ESTELON. This constitutes the pur chasers sole remedy.
- Page 20 Customers should consult with their original ESTELON dealer or distributor for possible alternate repair instructions prior to contacting the ESTELON factory. BUT under any and all circumstances customers are welcome to contact our sales department, as listed on our web site www.estelon.com, for service assistance.
