Summary of Contents for Estelon YB
- Page 1 Y-Series: Model YB Limited Edition CHAMPAGNE GOLD USER’S MANUAL...
- Page 2 Your ESTELON loudspeakers have passed our quality control: Technical test passed. Andrus Aaslaid Engineer, Alfred & Partners Listening test passed. Alfred Vassilkov Head of Research and Development, Alfred & Partners SERIAL NUMBER: Only 50 pairs of the Limited Edition “Champagne Gold” Model YB are available worldwide!
- Page 3 Alfred has more than 30 years of experience in designing and engineering loudspeakers. It is a lifetime of experience, profound knowledge of science, fanatical attention to detail and a fine sense of design that he has united into one beautiful handmade line of products – Estelon Y Series.
-
Page 4: Technical Specifications
TECHNICAL SPECIFICATIONS Woofer: 8” Mid Woofer: 5,25” Tweeter: 1” Beryllium Internal Wiring: Kubala-Sosna Frequency Response: 30 - 40 000 Hz Power Rating: 150 W Amplifier Power: Minimum 30 W Nominal Impedance: 6 Ohms Sensitivity: 86 dB/2.83 V Height: 1285mm Width: 365mm Depth: 430mm Net Weight Total:... -
Page 5: Unpacking Instructions
UNPACKING INSTRUCTIONS Your Estelon Model YB loudspeakers come packaged each in a carton box. For shipping, both boxes are packed in a plywood crate – we strongly recommend keeping the original package for possible future use / transport. The crate is collapsible for easier storage. - Page 6 When positioning the speakers in your room, if possible, it is desirable to allow for “free” space around the speakers so as to assist in minimizing sound reflections from walls, furniture etc. This will help in achieving correct tonality, realistic imaging, focus and dynamics. The recommended minimum distance between the speaker and the nearest reflection point is 1.0 m.
- Page 7 Packing the speakers: For packing follow the same procedures in the opposite direction.
-
Page 8: Setting Up The System
/ writing on the cable. Break-in period: Although your Estelon speakers had an initial break-in at the factory, due to shipping conditions - pressure/temperature changes that they may have incurred, the speakers will need to go through an additional break-in process before their final set-up and tuning. - Page 9 For critical listening, please allow 60-90 minutes for the system to stabilize, each time you play the speakers. When played at excessive volume, you stand the risk of doing damage to the drivers. If you have any questions, please contact authorized Estelon dealer for assistance.
-
Page 10: Taking Care Of Your Estelon Speakers
TAKING CARE OF YOUR ESTELON SPEAKERS The multicoated finishes applied to Estelon speakers are considered to be amongst the most advanced automotive finishes available. They are extremely strong and durable. In order to assist you in maintaining their stunning appearance, your Estelon loudspeakers come supplied, from the factory, with special cleaning / polishing cloths. - Page 11 All units for repair, service, scrap etc. must be returned to Scan-Speak (check the shipping address with Estelon factory first) and they will take care of recycling the beryllium dome. Put the tweeter into a plastic bag inside a cardboard box.
-
Page 12: Technical Services
Alfred & Partners OÜ Five Year Limited Warranty Terms and Conditions 1. Limited Warranty – All ESTELON products purchased from autho- rized ESTELON dealers are covered by a limited 5-year non-trans- ferrable warranty granted by Alfred & Partners OÜ. This warranty... - Page 13 ESTELON. This constitutes the purchasers sole remedy. 5. Design Changes – ESTELON reserves the right to modify its products or change specifications at any time without obligation or liability to previous purchasers.
- Page 14 2. Upon clicking the ‘Submit’ button on the Return Authorization Form, the ESTELON factory will review it for completeness and return an e-mail to you with an RA number when required (please allow 2-5 days for a return e-mail).
- Page 15 All non warranty repairs are warranted for one year from the date of return shipment. Have we answered all your questions? If not, please send us an email with your questions to sales@estelon.com www.estelon.com...
- Page 16 Estelon Model YB is handmade in Estonia ESTELON is a trademark of Alfred & Partners OÜ Alfred & Partners OÜ Tanuma 126 13521 Tallinn Estonia...
