Our Recommendations; A Note About Covering Material - Model Tech Mini Mach Racer Assembly Instructions Manual

This section describes our recommendations to help you in deciding which types of accessories to purchase for your new aircraft.
Please read through this entire section very carefully. We have provided you with recommendations that, if
followed, will result in a great flying aircraft. Failure to follow our recommendations may result in a poor
flying aircraft.
The Mini Mach Racer EP ARF is designed to use a brushless outrunner motor and a 3 cell LiPO battery. For good overall flight
performance, we recommend using the KMS Quantum 2208/09 brushless outrunner motor, the KMS 18 amp brushless electronic speed
control, an APC 6 x 4 propeller, and the Impulse Power 3 Cell 950mAH LiPO battery. It's also important that you used high-quality
connectors, such as X'tra 2mm Gold Plugs.
IMPORTANT The elevon servos will plug separately into your receiver or elevon mixer (if your transmitter does not feature elevon
mixing). The use of a Y-Harness for the elevon servos is not necessary.
here's a lisT of WhaT We reCoMMeNd To fiNish The MiNi MaCh raCer eP arf
QTY. 1 Airtronics RD6000 FM Radio Control System
QTY. 1 KMS Quantum 2208/09 Brushless Outrunner Motor
QTY. 1 KMS 18 Amp Brushless ESC
QTY. 2 Airtronics 94091Z Micro Servos
QTY. 1 Cirrus RX-8 FM Dual Conversion Receiver
QTY. 1 Cirrus Crystal for FM Dual Conversion Receivers
The covering material used on your aircraft is real iron-on, heat-shrink covering material. It is possible with heat and humidity changes
that the covering material on your aircraft may wrinkle or sag. This trait is inherent in all types of heat-shrink material. To remove any
wrinkles that might be visible you will need to use a heat-sealing covering iron.
follow this simple procedure to remove the wrinkles:
q Plug in and turn on the sealing iron to the medium-high temperature setting. Allow the sealing iron to heat up for approximately 5 - 7 minutes.
q After the sealing iron has reached temperature, lightly apply the sealing iron to the wrinkled section of the covering material. Move
the sealing iron slowly over the wrinkled section until the covering material tightens and the wrinkles disappear.
+
If the color layer smears from any of the seams the temperature of the sealing iron is too hot. Turn the temperature dial down and
wait about 5 minutes for the sealing iron to adjust to the lower temperature. You can remove any excess color streaks using a paper
towel soaked with a small quantity of acetone.

our reCoMMeNdaTioNs

reCoMMeNded brushless PoWer sysTeM
REcoMMEnDED RADio, REcEivER AnD SERvoS
You will need to use a 4 or more channel transmitter that features elevon mixing, two 9 gram
micro servos and a micro or mini receiver with matching crystal. At a minimum, the transmitter
should also feature dual rates, servo reversing and end-point adjustments. do not use
short-range micro receivers.
If your transmitter does not feature elevon mixing, you will need to purchase a separate electronic
elevon mixer that is installed in the aircraft.
QTY. 1
QTY. 1
QTY. 1
QTY. 1
QTY. 1
QTY. 1

A noTE ABoUT covERinG MATERiAL

Page
KMS Quantum 2208/09 Brushless Outrunner
l
KMS 18 Amp Brushless ESC
l
APC 6 x 4 Composite Propeller
l
Impulse Power 3C 950mAH LiPO Battery
l
Pro-Peak Quattro DC LiPO Charger
l
X'tra 2mm Gold Plugs
l
Impulse Power 3 Cell 950mAH (25C) LiPO Battery
APC 6 x 4 Composite Propeller
Pro-Peak Quattro DC LiPO Charger
X'tra 2mm Gold Connector Set
Double-Sided Foam Tape
Great Planes 1/4" (3mm) Black Striping Tape (Optional)
