11
Plug the two ends from the ignition to the coil.
Green cable goes in green plug.
12
3 mm and 5 mm Fixed Wrench
a. Attach the red cable to the electric starter
using the screw there is in it.
b. Unscrew the 5 mm Allen screw. Insert the
earth cable (black) plug into the screw and
screw firmly.
13
Cover both cables ends with the plastic covers
inserted in the cables.
14
10 mm Fixed Wrench
Attach the fuel pump to the free end of the
same silent block where the ground cable has
been attached in point
nut and washer provided.
Via dei Soprini, 16 – 25080 PREVALLE (Brescia) ITALY-Tel. +39 030 6804601 – Fax +39 030 6804698
.
6 Secure it with 6 mm.
