21
Pass the main wire loom under the seat and
secure it to the chassis by using plastic cable
ties. Make sure there is no loose wiring that
may drag on the track.
22
Plug in the electric plug coming from the battery to
the other half located aside the engine.
23
a. Cover the inside of the RPM limiter box
cradle with the specific foam tape provided.
Fit a small piece of fuel line to the O.R as
illustrated in the picture and secure the RPM
limiter box to the cradle with the O.R.
b. Attach the cradle to the seat or the chassis.
c. Insert the female plug coming from the
ignition on the male plug in the RPM limiter
box.
24
Hook the two springs provided into the exhaust
manifold.
