Product Manual
Seagate
Enterprise Capacity 3.5 HDD v4
®
Serial ATA
Standard 4KN models
ST6000NM0004
ST4000NM0004
ST2000NM0004
Self-Encryption 4KN models
ST6000NM0064
ST4000NM0064
ST2000NM0064
SED (FIPS 140-2) 4KN model
(Review Pending)
ST6000NM0094
100740544
Rev. C
June 2014
Standard 5xxE models
ST6000NM0024
ST5000NM0084
ST4000NM0024
ST2000NM0024
Self-Encryption 5xxE models
ST6000NM0044
ST4000NM0044
ST2000NM0044
SED (FIPS 140-2) 5xxE model
(Review Pending)
ST6000NM0084
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Seagate ST6000NM0004
Summary of Contents for Seagate ST6000NM0004
- Page 1 Product Manual Seagate Enterprise Capacity 3.5 HDD v4 ® Serial ATA Standard 4KN models Standard 5xxE models ST6000NM0004 ST6000NM0024 ST4000NM0004 ST5000NM0084 ST2000NM0004 ST4000NM0024 ST2000NM0024 Self-Encryption 4KN models Self-Encryption 5xxE models ST6000NM0064 ST6000NM0044 ST4000NM0064 ST4000NM0044 ST2000NM0064 ST2000NM0044 SED (FIPS 140-2) 4KN model...
- Page 2 Publication number: 100740544, Rev. C June 2014 Seagate, Seagate Technology and the Wave logo are registered trademarks of Seagate Technology LLC in the United States and/or other countries. Constellation ES and SeaTools are either trademarks or registered trademarks of Seagate Technology LLC or one of its affiliated companies in the United States and/or other countries.
-
Page 3: Table Of Contents
Seagate Technology Support Services ........ - Page 4 S.M.A.R.T. commands ..........37 Seagate Enterprise Capacity 3.5 HDD v4 Serial ATA Product Manual, Rev. C...
-
Page 5: Seagate Technology Support Services
For information regarding Warranty Support, visit: http://www.seagate.com/support/warranty-and-replacements/ For information regarding data recovery services, visit: http://www.seagate.com/services-software/data-recovery-services/ For Seagate OEM and Distribution partner portal, visit: http://www.seagate.com/partners For Seagate reseller portal, visit: http://www.seagate.com/partners/my-spp-dashboard/ Seagate Enterprise Capacity 3.5 HDD v4 Serial ATA Product Manual, Rev. C... -
Page 6: Introduction
Note controller manufacturer to ensure use of full capacity is supported. For more information on FIPS 140-2 Level 2 certification see See Section 4.0 on page 25 . Seagate Enterprise Capacity 3.5 HDD v4 Serial ATA Product Manual, Rev. C... -
Page 7: About The Serial Ata Interface
Shadow Register Block. All Serial ATA devices behave like Device 0 devices. For additional information about how Serial ATA emulates parallel ATA, refer to the “Serial ATA: High Speed Serialized AT Attachment” specification. The specification can be downloaded from www.serialata.org. Seagate Enterprise Capacity 3.5 HDD v4 Serial ATA Product Manual, Rev. C... -
Page 8: Drive Specifications
5% to 95% (operating) Relative humidity 5% to 95% (nonoperating) Relative humidity gradient 30% per hour max –304.8 m to 3,048 m Altitude, operating (–1000 ft to 10,000+ ft) Seagate Enterprise Capacity 3.5 HDD v4 Serial ATA Product Manual, Rev. C... - Page 9 *One GB equals one billion bytes when referring to hard drive capacity. Accessible capacity may vary depending on operating environment and formatting. **During periods of drive idle, some offline activity may occur according to the S.M.A.R.T. specification, which may increase acoustic and power to operational levels. Seagate Enterprise Capacity 3.5 HDD v4 Serial ATA Product Manual, Rev. C...
-
Page 10: Formatted Capacity
I/O data-transfer rate (MB/s max) 600 (Ultra DMA mode 5) Start/stop times Power-on to Ready (sec) (typ/max) 23/30 Standby to Ready (sec) (typ/max) 23/30 Ready to spindle stop (sec) (max) Seagate Enterprise Capacity 3.5 HDD v4 Serial ATA Product Manual, Rev. C... -
Page 11: Power Specifications
3 0.60 1.06 15.72 *During periods of drive idle, some offline activity may occur according to the S.M.A.R.T. specification, which may increase acoustic and power to operational levels. Seagate Enterprise Capacity 3.5 HDD v4 Serial ATA Product Manual, Rev. C... - Page 12 3 0.72 1.22 18.24 *During periods of drive idle, some offline activity may occur according to the S.M.A.R.T. specification, which may increase acoustic and power to operational levels Seagate Enterprise Capacity 3.5 HDD v4 Serial ATA Product Manual, Rev. C...
- Page 13 3 0.61 0.74 11.93 *During periods of drive idle, some offline activity may occur according to the S.M.A.R.T. specification, which may increase acoustic and power to operational levels. Seagate Enterprise Capacity 3.5 HDD v4 Serial ATA Product Manual, Rev. C...
- Page 14 2.5.1.1 Typical current profiles Figure 1. 6TB & ST5000NM0084 Typical 5V startup and operation current profile Figure 2. 6TB & ST5000NM0084 Typical 12V startup and operation current profile Seagate Enterprise Capacity 3.5 HDD v4 Serial ATA Product Manual, Rev. C...
- Page 15 2.5.1.2 Typical current profiles Figure 3. 4TB Typical 5V startup and operation current profile Figure 4. 4TB Typical 12V startup and operation current profile Seagate Enterprise Capacity 3.5 HDD v4 Serial ATA Product Manual, Rev. C...
- Page 16 2.5.1.3 Typical current profiles Figure 5. 2TB Typical 5V startup and operation current profile Figure 6. 2TB Typical 12V startup and operation current profile Seagate Enterprise Capacity 3.5 HDD v4 Serial ATA Product Manual, Rev. C...
-
Page 17: Conducted Noise
• Reports the current power state of the drive Identify Device Command • EPC Feature set supported flag • EPC Feature enabled flag is set if at least one Idle power condition timer is enabled Seagate Enterprise Capacity 3.5 HDD v4 Serial ATA Product Manual, Rev. C... - Page 18 PowerChoice Supported Extended Power Condition Identifiers Power Condition Identifiers Power Condition Name Standby_z 01 - 80 Reserved Idle_a Idle_b Idle_c 84 - FE Reserved All EPC Power Conditions Seagate Enterprise Capacity 3.5 HDD v4 Serial ATA Product Manual, Rev. C...
-
Page 19: Environmental Limits
Non-operating –40° to 158°F (–40° to 70°C) package ambient with a maximum gradient of 36°F (20°C) per hour. This specification assumes that the drive is packaged in the shipping container designed by Seagate for use with drive. HDA Temp. -
Page 20: Shock
The maximum nonoperating vibration levels that the drive may experience without incurring physical damage or degradation in performance when subsequently put into operation are specified below. 10–500 Hz 5.0 Grms ref Linear Random Seagate Enterprise Capacity 3.5 HDD v4 Serial ATA Product Manual, Rev. C... -
Page 21: Acoustics
Seagate follows the ECMA-74 standards for measurement and identification of PDTs. An exception to this process is the use of the absolute threshold of hearing. Seagate uses this threshold curve (originated in ISO 389-7) to discern tone audibility and to compensate for the inaudible components of sound prior to computation of tone ratios according to Annex D of the ECMA- 74 standards. -
Page 22: Reliability
EN 55024. Drives are tested in representative end-user systems. Although CE-marked Seagate drives comply with the directives when used in the test systems, we cannot guarantee that all systems will comply with the directives. The drive is designed for operation inside a properly designed enclosure, with properly shielded I/O cable (if necessary) and terminators on all unused I/O ports. -
Page 23: 2.11.3 Fcc Verification
As a subassembly, no Federal Communications Commission verification or certification of the device is required. Seagate has tested this device in enclosures as described above to ensure that the total assembly (enclosure, disk drive, motherboard, power supply, etc.) does comply with the limits for a Class B computing device, pursuant to Subpart J, Part 15 of the FCC rules. -
Page 24: Environmental Protection
The silver, copper, nickel and gold films used in Seagate products are especially sensitive to the presence of sulfide, chloride, and nitrate contaminants. Sulfur is found to be the most damaging. In addition, electronic components should never be exposed to condensing water on the surface of the printed circuit board assembly (PCBA) or exposed to an ambient relative humidity greater than 95%. -
Page 25: Reference Documents
Product warranty Beginning on the date of shipment to the customer and continuing for the period specified in the purchase contract, Seagate warrants that each product (including components and subassemblies) that fails to function properly under normal use due to defect in materials or workmanship or due to nonconformance to the applicable specifications will be repaired or replaced, at Seagate’s option and at no charge to the customer, if returned by customer at customer’s expense to Seagate’s designated... -
Page 26: Configuring And Mounting The Drive
• Do not overtighten the mounting screws (maximum torque: 6 in-lb). • Do not cover breather hole on top cover. Figure 9. Breather hole location - top cover Seagate Enterprise Capacity 3.5 HDD v4 Serial ATA Product Manual, Rev. C... -
Page 27: Mechanical Specifications
SFF-8301 and SFF-8323, found at www.sffcommittee.org Figure 10. Mounting configuration dimensions (2TB & 4TB) The image is for mechanical dimension reference only and may not represent the actual drive. Note Seagate Enterprise Capacity 3.5 HDD v4 Serial ATA Product Manual, Rev. C... - Page 28 Figure 11. Mounting configuration dimensions (6TB models & ST5000NM0084) The image is for mechanical dimension reference only and may not represent the actual drive. Note Seagate Enterprise Capacity 3.5 HDD v4 Serial ATA Product Manual, Rev. C...
-
Page 29: About Fips
Figure 12. Example of FIPS tamper evidence labels. Image is for reference only, may not represent actual drive Note Seagate Enterprise Capacity 3.5 HDD v4 Serial ATA Product Manual, Rev. C... -
Page 30: About Self-Encrypting Drives
The Trusted Computing Group (TCG) is an organization sponsored and operated by companies in the computer, storage and digital communications industry. Seagate’s SED models comply with the standards published by the TCG. To use the security features in the drive, the host must be capable of constructing and issuing the following two ATA commands: •... -
Page 31: Random Number Generator (Rng)
In addition to providing a locking mechanism to prevent unwanted firmware download attempts, the drive also only accepts download files which have been cryptographically signed by the appropriate Seagate Design Center. Three conditions must be met before the drive will allow the download operation: 1. -
Page 32: Power Requirements
The drive shall not support the OVERWRITE EXT and BLOCK ERASE EXT sub-commands. Support of the SANITIZE FREEZE LOCK EXT command shall be determined on a customer-specific basis. OEM drives shall support the command. Seagate Enterprise Capacity 3.5 HDD v4 Serial ATA Product Manual, Rev. C... -
Page 33: Serial Ata (Sata) Interface
5V power Ground 2nd mate Ground or LED signal If grounded, drive does not use deferred spin Ground 1st mate. 12V power, pre-charge, 2nd mate 12V power 12V power Seagate Enterprise Capacity 3.5 HDD v4 Serial ATA Product Manual, Rev. C... -
Page 34: Supported Ata Commands
Read Log DMA Ext Read Log Ext Read Multiple Read Multiple Extended Read Sectors Read Sectors Extended Read Sectors Without Retries Read Verify Sectors Read Verify Sectors Extended Seagate Enterprise Capacity 3.5 HDD v4 Serial ATA Product Manual, Rev. C... - Page 35 Write DMA Write DMA Extended Write DMA FUA Extended Write FPDMA Queued Write Log DMA Ext Write Log Extended Write Multiple Write Multiple Extended Write Multiple FUA Extended Seagate Enterprise Capacity 3.5 HDD v4 Serial ATA Product Manual, Rev. C...
-
Page 36: Identify Device Command
Number of current logical sectors per logical track xxxx 57–58 Current capacity in sectors xxxx Number of sectors transferred during a Read Multiple or Write Multiple command xxxx Seagate Enterprise Capacity 3.5 HDD v4 Serial ATA Product Manual, Rev. C... - Page 37 Ultra DMA support and current mode (see note following this table) 007F Security erase time xxxx Enhanced security erase time xxxx Master password revision code FFFE Hardware reset value xxxx 95–99 ATA-reserved 0000 Seagate Enterprise Capacity 3.5 HDD v4 Serial ATA Product Manual, Rev. C...
- Page 38 Multiword DMA mode 2 is currently active. Word 84 SMART error logging is supported. SMART self-test is supported. Media serial number is supported. Media Card Pass Through Command feature set is supported. Seagate Enterprise Capacity 3.5 HDD v4 Serial ATA Product Manual, Rev. C...
- Page 39 Ultra DMA mode 3 is currently active. Ultra DMA mode 4 is currently active. Ultra DMA mode 5 is currently active. Ultra DMA mode 6 is currently active. Seagate Enterprise Capacity 3.5 HDD v4 Serial ATA Product Manual, Rev. C...
-
Page 40: Set Features Command
Enable read look-ahead (read cache) feature (default). Report full capacity available At power-on, or after a hardware or software reset, the Note default values of the features are as indicated above. Seagate Enterprise Capacity 3.5 HDD v4 Serial ATA Product Manual, Rev. C... -
Page 41: Commands
S.M.A.R.T. Return Status If an appropriate code is not written to the Features Register, the Note command is aborted and 0x 04 (abort) is written to the Error register. Seagate Enterprise Capacity 3.5 HDD v4 Serial ATA Product Manual, Rev. C... - Page 42 NDEX drive mounting 23 Accessible Max Address Configuration 30 acoustics 17 Electrical fast transient 17 Admin SP 26 Electromagnetic compatibility 18 AES-256 data encryption 26 Electromagnetic Compatibility (EMC) 19 Agency certification 18 Electromagnetic Compatibility control Regulation 19 altitude 15 Electromagnetic Compatibility Directive (2004/108/EC) 18 ambient 15 Electromagnetic immunity 17 ambient temperature 7...
- Page 43 NDEX Idle Immediate 30 power-on 36 Information Technology Equipment (ITE) 18 Power-on to Ready 6 Input noise ripple 13 precautions 22 input voltage 7 printed circuit board 22 interface 6 Prominent Discrete Tones 17 interference 19 protection of data at rest 26 internal data-transfer rate OD 6 ISO document 7779 17 ITE 18...
- Page 44 NDEX S.M.A.R.T. Return Status 31 S.M.A.R.T. Save Attribute Values 31 Vibration 16 S.M.A.R.T. Write Log sector 31 voltage 7 Safety certification 18 Voltage dips, interrupts 17 Sanitize Device 31 Voltage tolerance 13 sanitize device-crypto scramble ext 28 SATA 29 screws 16 sectors 6 wet bulb temperature 15 Secure ID 26...
- Page 45 Seagate Technology LLC 10200 South De Anza Boulevard, Cupertino, California 95014, United States, 408-658-1000 ASIA/PACIFIC Seagate Singapore International Headquarters Pte. Ltd. 7000 Ang Mo Kio Avenue 5, Singapore 569877, 65-6485-3888 EUROPE, MIDDLE EAST AND AFRICA Seagate Technology SAS 16-18 rue du Dôme, 92100 Boulogne-Billancourt, France, 33 1-4186 10 00 Publication Number: 100740544, Rev.
