Enterprise Capacity
Standard 4KN models
ST8000NM0065
ST6000NM0075
Standard Power Balance
4KN models
ST8000NM0175
Self-Encryption 4KN models
ST8000NM0095
ST6000NM0145
SED FIPS 4KN models
ST8000NM0125
3.5 HDD
v5 SAS Product Manual
Self-Encryption 512E models
100780698, Rev. F
April 2017
Standard 512E models
ST8000NM0075
ST6000NM0085
ST8000NM0085
ST6000NM0135
SED FIPS 512E models
ST8000NM0135
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Seagate ST8000NM0065
Summary of Contents for Seagate ST8000NM0065
- Page 1 Enterprise Capacity 3.5 HDD v5 SAS Product Manual Standard 4KN models Standard 512E models ST8000NM0065 ST8000NM0075 ST6000NM0075 ST6000NM0085 Standard Power Balance 4KN models ST8000NM0175 Self-Encryption 4KN models Self-Encryption 512E models ST8000NM0095 ST8000NM0085 ST6000NM0145 ST6000NM0135 SED FIPS 4KN models SED FIPS 512E models...
- Page 2 Seagate, Seagate Technology and the Spiral logo are registered trademarks of Seagate Technology LLC in the United States and/or other countries. Raid Rebuild and SeaTools are either trademarks or registered trademarks of Seagate Technology LLC or one of its affiliated companies in the United States and/or other countries. The FIPS logo is a certification mark of NIST, which does not imply product endorsement by NIST, the U.S., or Canadian governments.All other trademarks or registered trademarks are the property of their respective owners.
-
Page 3: Table Of Contents
Seagate® Technology Support Services ........ - Page 4 About FIPS................. . 35 Seagate Enterprise Capacity 3.5 HDD v5 SAS Product Manual, Rev. F...
- Page 5 Additional information ..............57 Seagate Enterprise Capacity 3.5 HDD v5 SAS Product Manual, Rev. F...
-
Page 6: Seagate® Technology Support Services
For information regarding online support and services, visit: http://www.seagate.com/about/contact-us/technical-support/ For information regarding Warranty Support, visit: http://www.seagate.com/support/warranty-and-replacements/ For information regarding data recovery services, visit: http://www.seagate.com/services-software/data-recovery-services/ For Seagate OEM, Distribution partner portal and reseller portal, visit: http://www.seagate.com/partners Seagate Enterprise Capacity 3.5 HDD v5 SAS Product Manual, Rev. F... -
Page 7: Scope
Scope This manual describes Seagate® Enterprise Capacity 3.5 HDD v5 SAS (Serial Attached SCSI) disk drives. Enterprise Capacity 3.5 HDD v5 drives support the SAS Protocol specifications to the extent described in this manual. The SAS Interface Manual (part number 100293071) describes the general SAS characteristics of this and other Seagate SAS drives. -
Page 8: Applicable Standards And Reference Documentation
Section 10.3. Standards The Enterprise Capacity 3.5 HDD v5 family complies with Seagate standards as noted in the appropriate sections of this manual and the Seagate SAS Interface Manual, part number 100293071. The drives are recognized in accordance with UL 60950-1 as tested by UL, CSA 60950-1 as tested by CSA, and EN60950-1 as tested by TUV. -
Page 9: European Union Restriction Of Hazardous Substances (Rohs)
RoHS Directive. A number of parts and materials in Seagate products are procured from external suppliers. We rely on the representations of our suppliers regarding the presence of RoHS substances in these parts and materials. Our supplier contracts require compliance with our chemical substance restrictions, and our suppliers document their compliance with our requirements by providing material content declarations for all parts and materials for the disk drives documented in this publication. -
Page 10: China Requirements - China Rohs 2
X：表示该有害物质至少在该部件的某一均质材料中的含量超出 GB/T 26572 规定的限量要求。 X: Indicates that the hazardous substance contained in at least one of the homogeneous materials used for this part is above the limit requirement of GB/T26572. Seagate Enterprise Capacity 3.5 HDD v5 SAS Product Manual, Rev. F... -
Page 11: Reference Documents
TCG Storage Security Subsystem Class Enterprise Specification, Rev. 1.0 Specification for Acoustic Test Requirement and Procedures Seagate part number: 30553-001 In case of conflict between this document and any referenced document, this document takes precedence. Seagate Enterprise Capacity 3.5 HDD v5 SAS Product Manual, Rev. F... -
Page 12: General Description
The drives also use a high-performance actuator assembly with a low-inertia, balanced, patented, straight arm design that provides excellent performance with minimal power dissipation. Seagate recommends validating the configuration with the selected HBA/RAID Note controller manufacturer to ensure use of full capacity is supported. Seagate Enterprise Capacity 3.5 HDD v5 SAS Product Manual, Rev. F... -
Page 13: Standard Features
• User-selectable logical block sizes for 512E (512, 520, 524 or 528 bytes per logical block). • Vertical, horizontal, or top down mounting Seagate Enterprise Capacity 3.5 HDD v5 SAS Self-Encrypting Drive models have the following additional features: • 16 independent data bands •... -
Page 14: Formatted Capacities
4224 for 4096 native drives. Users having the necessary equipment may modify the data block size before issuing a format command and obtain different formatted capacities than those listed. To provide a stable target capacity environment and at the same time provide users with flexibility if they choose, Seagate recommends product planning in one of two modes: Seagate designs specify capacity points at certain block sizes that Seagate guarantees current and future products will meet. -
Page 15: Performance Characteristics
*Assumes no errors and no relocated logical blocks. Rate measured from the start of the first logical block transfer to or from the host. ** MiB/s x 1.048 = MB/s Seagate Enterprise Capacity 3.5 HDD v5 SAS Product Manual, Rev. F... -
Page 16: Start/Stop Time
If the STRICT bit in Mode page 00h (byte 2, bit 1) is set to one, the drive responds as it does for any attempt to change an unchangeable parameter. Seagate Enterprise Capacity 3.5 HDD v5 SAS Product Manual, Rev. F... -
Page 17: Caching Write Data
When prefetch (read look-ahead) is enabled (enabled by DRA = 0), the drive enables prefetch of contiguous blocks from the disk when it senses that a prefetch hit will likely occur. The drive disables prefetch when it decides that a prefetch hit is not likely to occur. Seagate Enterprise Capacity 3.5 HDD v5 SAS Product Manual, Rev. F... -
Page 18: Reliability Specifications
An interface error is defined as a failure of the receiver on a port to recover the data as transmitted by the device port connected to the receiver. The error may be detected as a running disparity error, illegal code, loss of word sync, or CRC error. Seagate Enterprise Capacity 3.5 HDD v5 SAS Product Manual, Rev. F... -
Page 19: Reliability And Service
Discharge the static electricity from the drive carrier prior to inserting it into the system. The drive motor must come to a complete stop prior to changing Caution the plane of operation. This time is required to insure data integrity. Seagate Enterprise Capacity 3.5 HDD v5 SAS Product Manual, Rev. F... - Page 20 This counter is referred to as the Failure History Counter. There is a separate Failure History Counter for each attribute. Seagate Enterprise Capacity 3.5 HDD v5 SAS Product Manual, Rev. F...
-
Page 21: Thermal Monitor
• Track-follow error after retries are exhausted • Read error after retries are exhausted • Write error after retries are exhausted Recovered errors will not be reported as diagnostic failures. Seagate Enterprise Capacity 3.5 HDD v5 SAS Product Manual, Rev. F... - Page 22 “not ready” cause. While not technically part of DST, a Not Ready condition also qualifies the drive to be returned to Seagate as a failed drive. A Drive Not Ready condition is reported by the drive under the following conditions: •...
-
Page 23: Product Warranty
See “Seagate® Technology Support Services” on page 5 for warranty contact information. Shipping When transporting or shipping a drive, use only a Seagate-approved container. Keep the original box. Seagate approved containers are easily identified by the Seagate Approved Package label. Shipping a drive in a non-approved container voids the drive warranty. -
Page 24: Physical/Electrical Specifications
• Specified and accumulated Start/Stops and Load/Unload cycles Power Condition Transitions Log Page reports (log page 0x1A, subpage 0x00) • Accumulated transitions to Active, Idle_A, Idle_B, Idle_C, Standby_Y, Standby_Z Seagate Enterprise Capacity 3.5 HDD v5 SAS Product Manual, Rev. F... -
Page 25: Ac Power Requirements
See +12V current profile in Figure 1. (for 4TB models) Seagate Enterprise Capacity 3.5 HDD v5 SAS Product Manual, Rev. F... -
Page 26: Conducted Noise Immunity
250 mV pp from 20 KHz to 5 MHz. 6.3.2 Power sequencing The drive does not require power sequencing. The drive protects against inadvertent writing during power-up and down. Seagate Enterprise Capacity 3.5 HDD v5 SAS Product Manual, Rev. F... -
Page 27: Current Profiles
The +12V (top) and +5V (bottom) current profiles for the Enterprise Capacity 3.5 HDD drives are shown below. Figure 1. 8TB model current profiles. Note All times and currents are typical. See Table 2 for maximum current requirements. Seagate Enterprise Capacity 3.5 HDD v5 SAS Product Manual, Rev. F... -
Page 28: Power Dissipation
+5 volt current, +12 volt current, and total watts on the vertical axis. To calculate BTUs per hour, multiply watts by 3.4123. Figure 2. 8TB and 6TB models (12Gb) DC current and power vs. input/output operations per second Seagate Enterprise Capacity 3.5 HDD v5 SAS Product Manual, Rev. F... -
Page 29: Environmental Limits
Non-operating –40° to 158°F (–40° to 70°C) package ambient with a maximum gradient of 36°F (20°C) per hour. This specification assumes that the drive is packaged in the shipping container designed by Seagate for use with drive. HDA Temp. -
Page 30: Shock And Vibration
Disk drives shipped as loose load (not palletized) general freight will be packaged to withstand drops from heights as defined in the table below. For additional details refer to Seagate specifications 30190-001 (under 100 lbs/45 kg) or 30191-001 (over 100 lbs/ 45 Kg). - Page 31 36 in (914 mm) Drives packaged in single or multipacks with a gross weight of 20 pounds (8.95 kg) or less by Seagate for general freight shipment shall withstand a drop test from 48 in (1070 mm) against a concrete floor or equivalent.
-
Page 32: Acoustics
Seagate recommends that data centers be kept clean by monitoring and controlling the dust and gaseous contamination. Gaseous contamination should be within ANSI/ISA S71.04-2013 G2 classification levels (as measured on copper and silver coupons), and dust contamination to ISO 14644-1 Class 8 standards, and MTBF rated conditions as defined in the Annualized Failure Rate (AFR) and Mean Time Between Failure (MTBF) section. -
Page 33: Mechanical Specifications
SFF-8301 and SFF-8323, found at www.sffcommittee.org. Figure 5. Mounting configuration dimensions (8TB & 6TB models) Note The image is for mechanical dimension reference only and may not represent the actual drive. Seagate Enterprise Capacity 3.5 HDD v5 SAS Product Manual, Rev. F... -
Page 34: About Self-Encrypting Drives
The Trusted Computing Group (TCG) is an organization sponsored and operated by companies in the computer, storage and digital communications industry. Seagate’s SED models comply with the standards published by the TCG. To use the security features in the drive, the host must be capable of constructing and issuing the following two SCSI commands: •... -
Page 35: Data Bands
In order to execute the RevertSP method the unique PSID (Physical Secure ID) printed on the drive label must be provided. PSID is not electronically accessible and can only be manually read from the drive label or scanned in via the 2D barcode. Seagate Enterprise Capacity 3.5 HDD v5 SAS Product Manual, Rev. F... -
Page 36: About Fips
Figure 6. Example of FIPS tamper evidence labels. Image is for reference only, may not represent actual drive Note Seagate Enterprise Capacity 3.5 HDD v5 SAS Product Manual, Rev. F... -
Page 37: Defect And Error Management
SCSI defect and error management involves drive internal defect/error management and SAS system error considerations (errors in communications between the initiator and the drive). In addition, Seagate provides the following technologies used to increase data integrity and drive reliability: •... -
Page 38: Sas System Errors
Status returned by the drive to the initiator is described in the SAS Interface Manual. Status reporting plays a role in systems error management and its use in that respect is described in sections where the various commands are discussed. Seagate Enterprise Capacity 3.5 HDD v5 SAS Product Manual, Rev. F... -
Page 39: Background Media Scan
This is in contrast to the system having to use the Reassign Command to reassign a location that was unreadable and then generate a write command to rewrite the data. DAR is most effective when AWRE and ARRE are enabled—this is the default setting from the Seagate factory. With AWRE and ARRE disabled DAR is unable to reallocate the failing location and will report an error sense code indicating that a write command is being attempted to a previously failing location. -
Page 40: Protection Information (Pi)
Types supported and which PI fields the drive supports checking. Note For further details with respect to PI, please refer to SCSI Block Commands - 3 (SBC-3) Draft Standard documentation. Seagate Enterprise Capacity 3.5 HDD v5 SAS Product Manual, Rev. F... -
Page 41: Installation
The drive may be mounted in any orientation. All drive performance characterizations, however, have been done with the drive in horizontal (discs level) and vertical (drive on its side) orientations, which are the two preferred mounting orientations. Seagate Enterprise Capacity 3.5 HDD v5 SAS Product Manual, Rev. F... -
Page 42: Cooling
Note. Air flows in the direction shown or in reverse direction (side to side) Figure 8. Air flow Note Image is for reference only, may not represent actual drive. Seagate Enterprise Capacity 3.5 HDD v5 SAS Product Manual, Rev. F... -
Page 43: Drive Mounting
Increased radiated emissions may result if users do not provide the maximum surface area ground connection between system ground and drive ground. This is the system designer’s and integrator’s responsibility. Seagate Enterprise Capacity 3.5 HDD v5 SAS Product Manual, Rev. F... -
Page 44: Interface Requirements
• Concurrent port transfers—The drive supports receiving COMMAND, TASK management transfers on both ports at the same time. • Full duplex—The drive supports sending XFER_RDY, DATA and RESPONSE transfers while receiving frames on both ports. Seagate Enterprise Capacity 3.5 HDD v5 SAS Product Manual, Rev. F... -
Page 45: Scsi Commands Supported
Lock-unlock cache Log Select PCR bit DU bit DS bit TSD bit ETC bit TMC bit LP bit Log Sense Application Client Log page (0Fh) Buffer Over-run/Under-run page (01h) Seagate Enterprise Capacity 3.5 HDD v5 SAS Product Manual, Rev. F... - Page 46 DPO bit supported FUA bit supported Read (12) Read (16) Read (32) 7Fh/0009h Read Buffer (modes 0, 2, 3, Ah and Bh supported) Y (non-SED drives only) Read Capacity (10) Seagate Enterprise Capacity 3.5 HDD v5 SAS Product Manual, Rev. F...
- Page 47 Supported Diagnostics pages (00h) Translate page (40h) Set Limits Start Unit/Stop Unit (spindle ceases rotating) Synchronize Cache Synchronize Cache (16) Test Unit Ready Verify (10) BYTCHK bit Verify (12) Verify (16) Seagate Enterprise Capacity 3.5 HDD v5 SAS Product Manual, Rev. F...
- Page 48 A = Support is available on special request. Approximately 1.5 increase in time to complete this command for a SED drive versus a non-SED drive of the same capacity. Seagate Enterprise Capacity 3.5 HDD v5 SAS Product Manual, Rev. F...
-
Page 49: Inquiry Data
Eight ASCII digits representing the eight digits of the product serial number. Bytes 16 through 26 reflect model of drive. The table above shows the hex values for Model ST8000NM0065. Refer to the values below for the values of bytes 16 through 26 of a particular model:... -
Page 50: Mode Sense Data
The following tables list the values of the data bytes returned by the drive in response to the Mode Sense command pages for SCSI implementation (see the SAS Interface Manual ). DEF = Default value. Standard OEM drives are shipped configured this way. CHG = Changeable bits; indicates if default value is changeable. Seagate Enterprise Capacity 3.5 HDD v5 SAS Product Manual, Rev. F... - Page 51 1A 26 01 0F FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 FC DEF: 1C 0A 10 00 00 00 00 00 00 00 00 01 CHG: 1C 0A 9D 0F FF FF FF FF FF FF FF FF Seagate Enterprise Capacity 3.5 HDD v5 SAS Product Manual, Rev. F...
- Page 52 1A 26 01 0F FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 FC DEF: 1C 0A 10 00 00 00 00 00 00 00 00 01 CHG: 1C 0A 9D 0F FF FF FF FF FF FF FF FF Seagate Enterprise Capacity 3.5 HDD v5 SAS Product Manual, Rev. F...
-
Page 53: Miscellaneous Operating Features And Conditions
Figure 9 shows the location of the SAS device connector J1. Figures 10 and 11 provide the dimensions of the SAS connector. Details of the physical, electrical, and logical characteristics are provided within this section. The operational aspects of Seagate’s SAS drives are provided in the SAS Interface Manual. - Page 54 SEE Detail1 33.43 0.05 15.875 15.875 1.27 (14X) 1.27 (6X) 0.84 0.05 (22X) 5.08 0.15 B 4.90 0.08 0.35MIN C OF DATUM B Figure 10. SAS device plug dimensions Seagate Enterprise Capacity 3.5 HDD v5 SAS Product Manual, Rev. F...
- Page 55 0.08 0.05 TO DATUM A 0.03 1.90 0.08 1.23 0.05 Detail 2 0.08 0.05 2.40 0.08 0.10 A SECTION B - B Figure 11. SAS device plug dimensions (detail) Seagate Enterprise Capacity 3.5 HDD v5 SAS Product Manual, Rev. F...
-
Page 56: Physical Characteristics
** - Power Disable (T10 Industry Standard) for remote management of the end device. Allows power cycling / power saving to be controlled by the host via interface pin 3. NC - No connection in the drive. Seagate Enterprise Capacity 3.5 HDD v5 SAS Product Manual, Rev. F... -
Page 57: Sas Transmitters And Receivers
LED off, high 0 V ≤ VOH ≤ 3.6 V -100 μA < IOH < 100 μA LED on, low IOL = 15 mA 0 ≤ VOL ≤ 0.225 V Seagate Enterprise Capacity 3.5 HDD v5 SAS Product Manual, Rev. F... -
Page 58: Differential Signals
Additional information Please contact the Seagate representative for SAS electrical details, if required. For more information about the Phy, Link, Transport, and Applications layers of the SAS interface, refer to the Seagate SAS Interface Manual, part number 100293071. For more information about the SCSI commands used by Seagate SAS drives, refer to the Seagate SCSI Commands Reference Manual, part number 100293068. - Page 59 ASIA/PACIFIC Seagate Singapore International Headquarters Pte. Ltd. 7000 Ang Mo Kio Avenue 5, Singapore 569877, 65-6485-3888 EUROPE, MIDDLE EAST AND AFRICA Seagate Technology SAS 16-18 rue du Dôme, 92100 Boulogne-Billancourt, France, 33 1-4186 10 00 Publication Number: 100780698, Rev. F...
