Chapter 2: Camera Configuration
IR Cut Filter (ICR) Control
Auto
When enabled, the camera will automatically turn the infrared lights on or
off based on the lighting levels in the environment.
Day Mode
Enables day mode and turns the IR cut filter control off.
Night Mode
Enables night mode and turns the IR cut filter control on.
Schedule ICR
Enables or disables IR cut filter control function to activate at the specified
time. You can configure the Start Time and End Time in 24-hour format.
Use Mode (During Scheduled Hours)
Selects the IR cut filter control mode to use during the scheduled time.
Use Mode (Outside of the Scheduled Hours)
Selects the IR cut filter control mode to use outside of the scheduled time.
Gamma Control
Default
Activates the default gamma state.
Gamma
Adjusts the gamma manually, the range is 0.01 ~ 1.00, with 0.01 being the
lowest value.
Copyright © 2013 NEXCOM International Co., Ltd. All Rights Reserved.
Color Filter
Remove Red
Adds red filters to the camera's view.
Remove Green
Adds green filters to the camera's view.
Remove Blue
Adds blue filters to the camera's view.
TV System
50Hz (PAL)
Configures the camera to 50Hz (PAL) mode. Select this when using in 50Hz
(PAL) countries to reduce flicker.
60Hz (NTSC)
Configures the camera to 60Hz (NTSC) mode. Select this when using in
60Hz (NTSC) countries to reduce flicker.
Save
Save button to apply the configurations, click on this button once all the
settings are confirmed for the new changes to take effect.
Reset
Reset button to discard all the settings applied.
41
NCb-231 User Manual
