2.5in USB 2.0 FireWire SATA External
Hard Drive Enclosure
SAT2510U2F
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
For the most up-to-date information, please visit: www.startech.com
Manual Revision: 11/16/2012
*actual product may vary from photos
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for StarTech.com SAT2510U2F
Summary of Contents for StarTech.com SAT2510U2F
- Page 1 DE: Bedienungsanleitung - de.startech.com FR: Guide de l'utilisateur - fr.startech.com ES: Guía del usuario - es.startech.com IT: Guida per l'uso - it.startech.com NL: Gebruiksaanwijzing - nl.startech.com PT: Guia do usuário - pt.startech.com For the most up-to-date information, please visit: www.startech.com Manual Revision: 11/16/2012...
- Page 2 StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby...
-
Page 3: Table Of Contents
Table of Contents Introduction ....................1 Packaging Contents ..........................1 System Requirements ..........................1 Installation ....................2 Hardware Installation ..........................2 Driver Installation ............................3 Using the Enclosure ................3 Specifications ..................5 Technical Support ..................6 Warranty Information ................6 Instruction Manual... -
Page 4: Introduction
Introduction The SAT2510U2F External Hard Drive Enclosure supports both USB 2.0 and FireWire 400 (IEEE1394a) host connections in a slim, lightweight aluminum design. Packaging Contents • 1 x 2.5” SATA drive enclosure • 1 x USB “Y” split cable • 1 x USB power cable •... -
Page 5: Installation
Installation WARNING! Hard drives require careful handling, especially when being transported. If you are not careful with your hard disk, lost data may result. Always handle your hard drive and storage device with caution. Hardware Installation 1. Remove the two small screws from either side of the rear panel of the enclosure and then pull the rear panel out. -
Page 6: Driver Installation
5. Connect the enclosure to the host computer system via FireWire or USB cable. If using the USB Y-cable, make sure to connect the primary connector on the cable to the host computer. The secondary connector is optional (extra power only). OPTIONAL: If the SATA drive/enclosure does not power up or is intermittent, additional power may need to be supplied. - Page 7 Locate the Disk that says it is “Unallocated” (check hard drive capacity to confirm it’s the correct hard drive) and then right-click in the section that says “Unallocated” and select “New Partition”. The New Partition Wizard will appear. Follow the instructions in the wizard to complete setting up the drive.
-
Page 8: Specifications
Specifications USB 2.0 Bus Interface FireWire400 (IEEE1394a) 1 x USB mini-B Connectors 1 x 6-pin FireWire 1 x DC power connector LEDs 1 x Power/Activity Chipset Initio INIC-1615 FW802C 2.5” SATA hard drive/solid state drive, up Compatible Hard Drives to 9.5mm height USB: 480Mb/s Maximum Data Transfer Rate FireWire: 400Mb/s... -
Page 9: Technical Support
Limitation of Liability In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product. - Page 10 StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology parts. StarTech.com was founded in 1985 and has operations in the United States, Canada, the United Kingdom and Taiwan servicing a worldwide market.
