STEP 3 – Setting up Capture
Turn the Rotary Switch to:
1. Time position, press A to set hour and B to set minutes.
Time is AM/PM format.
2. Date position, press A to set month and B to set date.
3. Year position, press A to go back and B to go forward.
STEP 4 – Attaching Capture to a tree
1. Attach Capture to a tree with the supplied strap.
2. We recommend mounting Capture about 3 feet off the ground.
3. Best image quality will be obtained if you position Capture about
10 to 15 feet from where animals are expected.
4. Capture can detect animals that are right in front of it out to 50
feet or more. Detection range will vary greatly with air temperature,
animal size and movement speed.
5. Remove any vegetation and obstructions from the Capture's field
of view that may interfere with the motion sensor or camera.
6. Aim and align the Capture as required. The Capture's TEST feature,
as explained next, can assist in this process.
STEP 5 – Test mode is used to check
Capture's detection zone
1. Turn the rotary switch to TEST.
2. Close the cover and completely tighten the thumb screw.
Detection range will be very short if the cover is left open.
3. Walk in front of Capture. The RED LED will illuminate when
you are detected.
4. When you are satisfied that Capture is aimed correctly, proceed
to Step 6.
