STEP 1 – Familiarize yourself with Capture
Take a moment to familiarize yourself with Capture's features.
STEP 2 – Turning Capture on
1. Mount the supplied tree bracket to the
back of the camera with the supplied screw.
2. Turn the rotary switch to the OFF position.
3. Install 4 new alkaline D cell batteries. Make sure to observe correct polarity.
4. A series of numbers will be displayed. These are the Capture's hardware and
software version numbers.
5. Wait until the LCD display goes blank and the green and red LEDs turn off.
6. Install the SD card into the SD card port. We recommend a 1 GB size card.
Hinge rod
"Stay-open" cover
2
Flash lens
Camera
window
Red LED
Heat-in-motion sensor
LCD screen
Operation keys
SD card port
Green LED
1
1. Push hinge rod
left to hold open
2. Push hinge rod
right to close
Rotary switch
