Mains power connection

Connect the low voltage plug from the power supply to the Power 18V DC socket of the phono amplifier
before connecting the power supply to the mains.

Connecting to a Computer

Connect the USB-output of the unit to a free USB-socket on your computer and turn it on/make sure it is
powered on.
The "new hardware found assistant" will automatically detect the unit and announces it as a Microphone USB
audio codec. There is no need to install a driver manually.
After installation, one setting has to be done. For example - Windows 7
 Control Panel  Sound  Recording  Microphone USB Audio CODEC  Properties 
Advanced: Set to 2 channels, 16 bit, 48000 Hz (DVD Quality)
Please note: Connection should be made to an USB-socket of your computer directly. Connecting to
USB-hubs or switches can cause problems.

Recording Programme

In case you do not have a recording programme installed on your computer, you may download one free from
the Internet. Recording programmes may be found by searching Google or Yahoo.
In the menu of the recording programme, source or input may have to be set to Microphone USB audio codec.
Please be aware that downloads from the Internet are made entirely at your own risk. Under no
circumstances can we carry responsibility or provide support for third-party software products sourced
from the internet or for any damage or problems arising from the use thereof. All downloads should
be checked with an up-to-date anti-virus programme. License fees may be applicable.

Technical specifications Pro-Ject Record Box E

A Typical for low output MC cartridges,
Input capacitance/input impedance, MC: 100ohms/120pF
Input capacitance/input impedance, MM: 47kohms/120pF
Gain, MM /MC:
Output voltage typically:
Max. output
Noise floor, MM / MC:
THD, MM / MC:
RIAA-equalisation curve accuracy:
A/D converter:
Sampling rates:
USB output:
USB signal:
Operating systems:
Input / Line output:
Outboard power supply:
Power consumption:
Dimensions W x H x D (D with sockets):
Weight:
B typical for MM or high output MC cartridges
A
B
40dB / 60dB
300mV/1kHz at 3mV/1kHz (MM) OR 0,3mV/1kHz (MC)
9,5V (1kHz)
94dB (A weighted) / 75dB (A weighted)
<0,01% / <0,05%
20Hz - 20kHz / max. 0,5dB
Burr Brown PCM2904 16-Bit Delta Sigma
32, 44,1 and 48kHz
5 pin mini b connector (USB cable supplied)
digital serial data protocol USB 1.1
®
Windows XP , Windows Vista
1 pair RCA/Cinch sockets / 1 pair RCA/Cinch sockets
18V/500mA DC, suitable for your country's mains supply
100mA DC
120 x 32 x 100 (115) mm
250g without power supply
© Pro-Ject Audio Systems · Pro-Ject Record Box E · Revision 2014.5.21
®
operating system:
® ®
, Windows 7 , Windows 8
®
, Mac OS
3
