- Page 1 Electronic Service Manuals This electronic document is provided as a service to our customers. We do not create the contents of the information contained in this docu- ment. Should you have detailed questions pertaining to the information contained in this document, you may contact Michco, or the manufac- turer which provided the original information in this electronic deliver- able.
- Page 2 This book has important information for the use and safe operation of this machine. Failure to read this book prior to operating or attempting any service or maintenance procedure to your Clarke machine could result in injury to you or to other personnel; damage to the machine or to other property could occur as well.
- Page 3 MODEL _______________________________________ DATE OF PURCHASE ___________________________ SERIAL NUMBER _______________________________ SALES REPRESENTATIVE # _____________________ DEALER NAME _________________________________ OPERATIONS GUIDE NUMBER ___________________ PUBLISHED ___________________________________ YOUR DEALER Name: _________________________________________________________________________ Address: _______________________________________________________________________ Phone Number: _________________________________________________________________ Page -2- Clarke ® Operator's Manual -Image Mini Spot...
-
Page 4: Table Of Contents
Solution Tank Group ......................5-3 Labels & Parts List ......................5-5 Hand Tool & Parts List ....................... 5-6 Spotter Cart & Parts List ....................5-7 Clarke Support Branches ....................5-8 Warranty ..........................5-9 Clarke ® Operator's Manual - Image Mini Spot... -
Page 5: Clarke ® Operator's Manual - Image Mini Spot
THIS PAGE LEFT BLANK INTENTIONALLY Page -4- Clarke ® Operator's Manual -Image Mini Spot... -
Page 6: How To Use This Manual
It contains replacement parts numbers needed for ordering future parts. The model and serial number of your machine is on the back underside of machine. Clarke ® Operator's Manual - Image Mini Spot Page 1-1... -
Page 7: Important Safety Instructions
Do not pull or carry by cord, use cord as a handle, close a door on cord, or pull cord around sharp edges or corners. Do not pull/run machine over cord. Keep cord away from heated surfaces. Connect to a properly grounded outlet. See Grounding Instructions. SAVE THESE INSTRUCTIONS Page 2-1 Clarke ® Operator's Manual -Image Mini Spot... -
Page 8: Hazard Intensity Level
In areas with possible falling objects. WHEN SERVICING MACHINE: Avoid moving parts. Do not wear loose clothing; jackets, shirts, or sleeves when working on the machine. Use manufacturer approved replacement parts. Clarke ® Operator's Manual - Image Mini Spot Page 2-2... -
Page 9: Grounding Instructions
Whenever the adaptor is used, it must be held in place by a metal screw. Page 2-3 Clarke ® Operator's Manual -Image Mini Spot... -
Page 10: Machine Operations
Remove as much moisture from system before solution in any one area. storing in cold climates. Excess water may freeze during storage and crack internal components, causing damage to the unit. Clarke ® Operator's Manual - Image Mini Spot Page 3-1... -
Page 11: Maintenance
Remove from solution tank. Locate the vacuum motor wires and disconnect at the connector. 4. Unfasten screws holding vac plate to switch plate. Remove the vacuum motor. 5. Reverse process to install vacuum motor replacement. Page 4-1 Clarke ® Operator's Manual -Image Mini Spot... -
Page 12: Wiring Diagram
Obstruction in cleaning tool Inspect for and remove any debris Recovery tank is not securely Tighten latch on back end of the machine mounted on the solution tank WIRING DIAGRAM Clarke ® Operator's Manual - Image Mini Spot Page 4-2... - Page 13 Clarke ® Image Mini Spot Recovery Tank Parts 12/02 Parts Inside Portal Cap Page 5-1 Clarke ® Operator's Manual -Image Mini Spot...
- Page 14 Clarke ® Image Mini Spot Recovery Tank Parts List 12/02 Ref. Part No. Description 52875A Asm. Acess Cover 52876A Screw, 8 x 3/4 PFHT/S BLK ZINC 52877A Float Asm. Spotter Weight 52878A Tube Asm. Spotter 52879A Screw, 10-32 x 3/8 PPHMS SS NP 50356A Bracket, Rec./Sol.
- Page 15 Clarke ® Image Mini Spot Solution Tank Parts 12/02 Page 5-3 Clarke ® Operator's Manual -Image Mini Spot...
- Page 16 Clarke ® Image Mini Spot Solution Tank Parts List 12/02 Ref. Part No. Description 52887A Tank, Spotter Sol. 52888A Hosebarb, 1/8 NPT x 3/8 90D Plastic 52889A Nipple, 1/8 FPT QD Male Brass 52890A Nipple, 1/8 Close 52891A Clamp, 3/8 Hose (D-Slot) 52892A Hose, 3/8"...
-
Page 17: Labels & Parts List
Clarke ® Image Mini Spot Labels and Parts List 12/02 Ref. Part No. Description 52977A Label, ALTO 52978A Label, Image Mini Spot 52979A Label, Clarke 52980A Label, For Safety 52981A Label, ON/OFF VAC/PUMP 52982A Label, Warning Page 5-5 Clarke ®... -
Page 18: Hand Tool & Parts List
Clarke ® Image Mini Spot Hand Tool and Parts List 12/02 Ref. Part No. Description 55179A Housing, Handtool Spotter 52983A Clamp DHT Valve 52984A Hose Asm. Hose/Cuff Connector 737141 Nipple, 1/8 FPT QD Fem. Brass 54177A Jet, Asm w/o Ring... - Page 19 ® Clarke Image Mini Spot Cart and Parts List 12/02 Ref. Part No. Description 61690A Handle Weldment, Cart 85520A Screw, 8-00 x 1/2 Pan Head 59951A Wheel, 8" 920346 Palnut 50007A Bumper, Recessed 81110A Nut Hex, Elastic Lock, 10-24 61689A...
- Page 20 Caringbah NSW 2229 ® Clarke , Carlstadt, New Jersey 07072 +61 2 9524 6122 150 Commerce Road (201) 460-4774 ALTO Cleaning Systems Asia Pte Ltd., Singapore No. 17 Link Road ® Clarke , Elk Grove, Illinois 60007 Singapore 619034 2280 Elmhurst Road...
-
Page 21: Warranty
(a). Return the product to the nearest Clarke repair location. Transportation charges to and from the repair location must be prepaid by the purchaser. (b). Clarke will repair the product and or replace any defective parts without charge within a reasonable time after receipt of the product.
