Operator's
TM
Manual
READ THIS BOOK
This book has important information for the use and safe operation of this machine. Failure to read this
book prior to operating or attempting any service or maintenance procedure to your Clarke machine
could result in injury to you or to other personnel; damage to the machine or to other property could
occur as well. You must have training in the operation of this machine before using it. If you or your
operator(s) cannot read English, have this manual explained fully before attempting to operate this
machine.
Si Ud. o sus operadores no pueden leer el Inglés, se hagan explicar este manual completamente antes
de tratar el manejo o servicio de esta máquina.
All directions given in this book are as seen from the operator's position at the rear of the machine.
®
For new books write to: Clarke
, 2100 Highway 265, Springdale, Arkansas 72764.
®
Clarke
Form No. 70781A 11/04
Printed in the U.S.A.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Clarke BextSpot 04153A
Summary of Contents for Clarke BextSpot 04153A
- Page 1 This book has important information for the use and safe operation of this machine. Failure to read this book prior to operating or attempting any service or maintenance procedure to your Clarke machine could result in injury to you or to other personnel; damage to the machine or to other property could occur as well.
-
Page 2: Table Of Contents
How to Correct Problems in the Machine ................7 Assembly Drawing ......................8 Parts List ........................ 9 Tool Assembly Drawing and Parts List ................10 Vacuum and Solution Hose Drawing and Parts List ............11 Authentic Clarke Products ....................12 Wiring Diagram ........................13 SPECIFICATIONS Part Number 04153A... -
Page 3: Operator Safety Instructions
WARNING: Any alterations or modifications of this machine could result in damage to the machine or injury to the operator or other bystanders. Alterations or modifica- tions not authorized by the manufacturer voids any and all warranties and liabilities. Clarke ® Page -3- Operator's Manual... -
Page 4: Grounding Instructions
Figure 1. Make sure that the product is connected to an outlet having the same configuration as the plug. No adapter should be used with this product. WARNING: DO NOT use an extension cord with this unit. ® Clarke Page -4- Operator's Manual... -
Page 5: How To Prepare The Machine For Operation
1. Fill the solution tank with clean hot or cold water. WARNING: Do not use water that is hotter than 140° 2. Use only brand name cleaner and mix the cleaner per package instructions Lift Handle Switches Vacuum Inlet Latch Quick Disconnect Figure2 Clarke ® Page -5- Operator's Manual... -
Page 6: Operating The Machine
Repair or replace the hose, if necessary. 4. Check spray tips daily. Clean spray tips, if plugged. 5. Monthly or as often as necessary, clean out any debris which may be in the vacuum tubing and hose. ® Clarke Page -6- Operator's Manual... -
Page 7: How To Correct Problems In The Machine
HOW TO CORRECT PROBLEMS IN THE MACHINE WARNING: Maintenance and repairs must be done by authorized personnel only. Use only Clarke parts. Maintenance performed by someone other than a Clarke distributor or Clarke replacement parts could void your warranty. Electrical System... -
Page 8: Assembly Drawing 11/04
® Clarke Assembly Drawing 11/04 35 36 ® Clarke Page -8- Operator's Manual... -
Page 9: Parts List
Clarke ® Assembly Parts List 11/04 Ref. Part No. Description 80258A Bolt, 10-32 x 4 F.H. 61385A Plate, Vacuum Mtg. 30485A Gasket, Vac Motor 40669A Motor, Vacuum 2 Stage 61386A Clamp, Vac Motor 40670A Switch, On/Off 61387A Plate, Switch 80259A... -
Page 10: Tool Assembly Drawing And Parts List
® Clarke Tool Assembly Drawing and Parts List 11/03 Ref. Part No. Description 59231A Hand Tool 737140 Quick Connector, 1/8 FPT Male 59618A Valve Assembly 55181A Valve Hanger 54177A Tee Jet, Plastic Orange Clarke ® Page -10- Operator's Manual... -
Page 11: Vacuum And Solution Hose Drawing And Parts List
® Clarke Vacuum and Solution Hose Assembly Drawing and Parts List 11/03 Ref. Part No. Description 737141 Quick Disconnect Female 30495A 1/4" x 10' Vacuum Hose 30493A 1 1/4" x 10' Vacuum Hose 699202 Cable Ties 30494A Hose Cuff Clarke ®... -
Page 12: Authentic Clarke Products
Authentic Clarke ® Products 11/03 Part No. Description 30108A Adaptor, 2" to 1½ 59231A RM-4P Tool Assembly 59230A RM-8P Tool Assembly 59229A RM-12M Tool Assembly 59232A Hide-A- Hose 10' 59228A RM-4M Tool Assembly 398426 Defoamer *1 case 51364A Odor Digestant... -
Page 13: Wiring Diagram 11/03
® Clarke Wiring Diagram 11/03 Clarke ® Page -13- Operator's Manual... - Page 14 NOTES...
- Page 15 +31 184 677 200 (201) 864-5503 ALTO Sverige AB, Molndal (Sweden) Aminogatan 18 ® Clarke Box 4029 Clarke American Sanders A.L. Cook S-431 04 Molndal Customer Service Headquarters and Factory +46 31 706 73 00 2100 Highway 265 Springdale, Arkansas 72764...
- Page 16 (a). Return the product to the nearest Clarke repair location. Transportation charges to and from the repair location must be prepaid by the purchaser. (b). Clarke will repair the product and or replace any defective parts without charge within a reasonable time after receipt of the product.
