This book has important information for the use and safe operation of this machine. Failure to read
this book prior to operating or attempting any service or maintenance procedure to your Clarke
machine could result in injury to you or to other personnel; damage to the machine or to other property
could occur as well. You must have training in the operation of this machine before using it. If your
operator(s) cannot read this manual, have it explained fully before attempting to operate this machine.
All directions given in this book are as seen from the operator's position at the rear of the machine.
For new books write to: Clarke
Form No. 823 0062 160
10/05
SUMMIT
9/13/20/20D
120V
Wet/Dry Vacuum
Operator's Manual
Libro de Instrucciones
Manuel d'utilisation
®
, 2100 Highway 265, Springdale, Arkansas 72764.
Clarke
®
EN
English
ES
Español
FR
Français
Printed in the U.S.A.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Clarke SUMMIT 3
Summary of Contents for Clarke SUMMIT 3
- Page 1 This book has important information for the use and safe operation of this machine. Failure to read this book prior to operating or attempting any service or maintenance procedure to your Clarke machine could result in injury to you or to other personnel; damage to the machine or to other property could occur as well.
-
Page 2: Table Of Contents
Instructions for Use ....................17 Use and Service Instructions, when used in hazardous substance recovery ..20 SECTION II - Parts List and Drawings ..............23 Page -2 - Clarke ® Operator's Manual - Summit 9, 13, 20 & 20D... - Page 3 Todas las instrucciones están dadas desde la posición del operador, en la parte de atrás de la máquina. Puede Ud. conseguir libros suplementarios dirigiéndose a su distribuidor Clarke. Indice Instrucciones importantes de seguridad............7 Especificaciones ....................
- Page 4 Toutes les instructions doivent être visualisées depuis la position du conducteur, à l’arrière de la machine. Des manuels supplémentaires peuvent être obtenus auprès de votre revendeur Clarke INDEX Importantes instructiond de sécurité ..............9 Caracteristiques ....................
-
Page 5: Important Safety Instructions
13. Turn off all controls before unplugging. 14. Use extra care when cleaning on stairs. 16. Connect to properly grounded outlet. See "Grounding Instructions". SAVE THESE INSTRUCTIONS Clarke ® Operator's Manual - Summit 9, 13, 20 & 20D Page - 5... - Page 6 DANGER: Failure to read the Owner's Manual prior to operating or attempting any service or maintenance procedure to your Clarke machine could result in injury to you or to other personnel; damage to the machine or to other property could occur as well. You must have training in the operation of this machine before using it.
-
Page 7: Instrucciones Importantes De Seguridad
16. Conecte la máquina sólo con una caja de enchufe con puesta a tierra. Véase las "Instrucciones para la conexión". GUARDE CUIDADOSAMENTE ESTAS INSTRUCCIONES DE SEGURIDAD Clarke ® Operator's Manual - Summit 9, 13, 20 & 20D Page - 7... - Page 8 Nunca opere una máquina a menos que esté completamente montada. Compruebe cuidadosamente el estado de la máquina antes de cada utilización. Siga las instrucciones de utilización descritas en este libro. Use sólo accesorios Clarke. AVISO: Si no sigue las instrucciones de seguridad indicadas por los adhesivos, se pueden causar lesiones o daños materiales.
- Page 9 16. "Ne brancher qu'à une prise de courant avec mise à la terre. Voir les instructions visant la mise à la terre." CONSERVER CES INSTRUCTIONS Clarke ® Operator's Manual - Summit 9, 13, 20 & 20D...
- Page 10 Ne jamais mettre la machine en service avant de l'avoir complètement montée. Vérifier soigneusement l'état de la machine avant chaque utilisation. Respecter le mode d'utilisation figurant dans ce manuel. N'utiliser que des accessoires Clarke. AVERTISSEMENT: Le non-respect des consignes de sécurité signalées par les autocollants peut provoquer des blessures ou des dégâts matériels.
-
Page 11: Specifications
Si l'appareil est utilisé pour aspirer des substances dangereuses, ne jamais tenter de l'ouvrir ou de le vider sans porter de vêtements protecteurs et une protection respiratoire. HEPA-FILTER REPLACEMENT, REMPLACEMENT DE FILTRE Clarke ® Operator's Manual - Summit 9, 13, 20 & 20D... - Page 12 Page -12 - Clarke ® Operator's Manual - Summit 9, 13, 20 & 20D...
- Page 13 Clarke ® Operator's Manual - Summit 9, 13, 20 & 20D Page - 13...
-
Page 14: Grounding / Double Insulation Instructions
14 AWG. Do not use an extension cord longer than 50 feet. Do not join two extension cords. Grounded Outlet Grounded Outlet Grounding Figure 1 ® Page -14 - Clarke Operator's Manual - Summit 9, 13, 20 & 20D... -
Page 15: Instrucciones Para Puesta A Tierra / Doble Aislación
15 metros de largo. Nunca conecte dos añadidos. Toma corriente con polo de tierra Tapa del toma corriente con Terminal polo de tierra. de tierra Figure 1a ® Clarke Operator's Manual - Summit 9, 13, 20 & 20D Page - 15... - Page 16 Prise de courant avec mise à la tere Boîte de sortie mise à Broche de la terre mise à la terre Figure 1b Page -16 - Clarke ® Operator's Manual - Summit 9, 13, 20 & 20D...
-
Page 17: Instructions For Use
Make sure the bag is pushed on as far as it will go. During use, check the bag frequently and remove and dispose of when full. Clarke ® Operator's Manual - Summit 9, 13, 20 & 20D... -
Page 18: Instrucciones De Uso
La máquina Summit 9 vacie el depósito hacéndolo bascular hacia atrás y vierta el contenido en un desagüe del suelo o similar. Page -18 - Clarke ® Operator's Manual - Summit 9, 13, 20 & 20D... - Page 19 L'Summit 9 vous suffit de retirer le bouchon et d'abaisser lentement le tuyau de vidange pour vidanger le contenu de l'appareil. Clarke ® Operator's Manual - Summit 9, 13, 20 & 20D Page - 19...
-
Page 20: Use And Service Instructions, When Used In Hazardous Substance Recovery
Operator's Manual. dance with all federal, state and local regulations. • Use only approved Clarke vacuum filters and bags. Attention Employer • The following is a recommended replacement interval for •... -
Page 21: Instrucciones De Empleo Y Servicio En La Recuperación De Sustancias Peligrosas
(EPA, OSHA), estatales y locales aplicables a la sustancia manejada. Clarke ® Operator's Manual - Summit 9, 13, 20 & 20D Page - 21... - Page 22 à toutes les réglementations prises le Manuel d'utilisation. fédérales, nationales et locales. • Utilisez uniquement les filres et sacs agréés par Clarke. Avertissement aux employeurs • Les instructions suivantes concernent les intervalles de • Veuillez vous assurer que les manuel d'utilisation et rempla cement recommandés pour touts les filtres et le...
-
Page 23: Section Ii - Parts List And Drawings
SUMMIT 9/13/20/20D 120V Wet/Dry Vacuum Section II Parts and Service (82300062160) Clarke ® Operator's Manual - Summit 9, 13, 20 & 20D Page - 23... - Page 24 NOTES Page -24 - Clarke ® Operator's Manual - Summit 9, 13, 20 & 20D...
- Page 25 Clarke ® Summit 9, 13, 20 & 20D Spare Parts List 9/05 Description Reference Head Assembly, Summit 9 Pages 26-27 Head Assembly, Summit 13, Summit 20 Pages 28-29 Head Assembly, Summit 20D Pages 30-31 Tank Assembly, Summit 9 Page 32...
- Page 26 Clarke ® Summit 9 Head Assembly Drawing 9/05 Page -26 - Clarke ® Operator's Manual - Summit 9, 13, 20 & 20D...
- Page 27 Clarke ® Summit 9 Head Assembly Parts List 9/05 Ref. # Part No. Description Qty. 140 8689 510 Motor, Vacuum 120V w/gaskets 140 9537 500 Switch two pole (package of 2) 147 0716 500 Cord, 16-3 x 50 feet 140 6560 500 Clamp, Cord w/screws...
- Page 28 Clarke ® Summit 13, Summit 20 Head Assembly Drawing 9/05 Page -28 - Clarke ® Operator's Manual - Summit 9, 13, 20 & 20D...
- Page 29 Clarke ® Summit 13, Summit 20 Head Assembly Drawing 9/05 Ref. # Part No. Description Qty. 140 9533 520 Cover, Outer 140 9527 510 Handle w/screws 140 8689 510 Motor, Vacuum 120V w/gaskets 140 7620 510 Internal wiring 140 6560 500 Clamp, Cord w/screws...
- Page 30 Clarke ® Summit 20D Head Assembly Drawing 9/05 Page -30 - Clarke ® Operator's Manual - Summit 9, 13, 20 & 20D...
- Page 31 Clarke ® Summit 20D Head Assembly Drawing 10/05 Ref. # Part No. Description Qty. 140 9531 520 Cover, Outer 140 9527 510 Handle w/screws 140 8689 520 Motor, Vacuum 120V 140 7620 540 Internal wiring 140 6560 500 Clamp, Cord w/screws...
- Page 32 Clarke ® Summit 9 Tank Assembly Drawing and Parts List 9/05 Ref. # Part No. Description Qty. 140 7204 500 Inlet with screws 140 8691 500 Latch w/screws (package of 2) 140 8672 530 Tank, 9 gallon Page -32 - Clarke ®...
- Page 33 ® Clarke Summit 13, Summit 20, Summit 20D Tank Assembly Drawing and Parts List 9/05 Ref. # Part No. Description Qty. 140 9517 500 Bracket, Tank w/screws 140 8685 500 Hook, Tank w/screws (pkg. of 2) 140 7604 500 Hose, Drain 140 9513 520 Tank (Summit 13) 140 9514 530 Tank (Summit 20 &...
- Page 34 Clarke ® Summit 9, Summit 13, Summit 20, Summit 20D Cart Assembly Drawing 9/05 Page -34 - Clarke ® Operator's Manual - Summit 9, 13, 20 & 20D...
- Page 35 Clarke ® Summit 9, Summit 13, Summit 20, Summit 20D Cart Assembly Parts List 9/05 140 8446 600 Wheel w/axle (pkg. of 2) (Summit 9) 140 8662 500 Frame (Summit 9) 140 6422 500 Caster (pkg. of 2) (Summit 9) 140 9519 500 Handle, trolley (Summit 13, 20 &...
- Page 36 Clarke ® Summit 13, Summit 20 Squeegee Assembly (PN 11050A) Drawing 9/05 Page -36 - Clarke ® Operator's Manual - Summit 9, 13, 20 & 20D...
- Page 37 ® Clarke Summit 13, Summit 20 Squegee Assembly (PN 11050A) Parts List 10/05 Ref. # Part No. Description Qty. 61808A Frame, squeegee 61809A Arm, Squeegee Lift 53727A Nut, thumb 5/16 140 2148 500 Hose, 1 1/2", length 25" 5620 9089 Squeegee 30"...
- Page 38 Clarke ® Summit 9, Summit 13, Summit 20, Summit 20D Nozzles and Hose Drawing 9/05 Page -38 - Clarke ® Operator's Manual - Summit 9, 13, 20 & 20D...
- Page 39 Clarke ® Summit 9, Summit 13, Summit 20, Summit 20D Nozzles and Hose Parts List 9/05 Ref. # Part No. Description Qty. Qty. 140 9598 500 Wet nozzle 1¼" 140 7629 000 Wet nozzle 1½" 140 9598 510 Dry nozzle, brush 1¼"...
- Page 40 Clarke ® Summit 9, Summit 13, Summit 20, Summit 20D Filter and Dust Bags Drawing and Parts List 9/05 Ref. # Part No. Description Qty. 147 0745 010 Dust bags, paper (Summit 9), 3 pack 147 0746 010 Dust bags, paper (Summit 13, 20 & 20D), 3 pack 140 8670 500 Cover HEPA (Summit 9), includes filter 140 8678 500 Filter HEPA (Summit 9, 12, 20 &...
- Page 41 Clarke ® Summit 9, Summit 13, Summit 20 Electrical Schematic 9/05 ® Clarke Summit 20D Electrical Schematic 9/05 Clarke ® Operator's Manual - Summit 9, 13, 20 & 20D Page - 41...
- Page 42 NOTES Page -42 - Clarke ® Operator's Manual - Summit 9, 13, 20 & 20D...
- Page 43 ALTO Cleaning Systems (UK) Ltd., Penrith (810) 544-6300 Gilwilly Industrial Estate Penrith ® American Lincoln / Clarke, Marietta, Georgia 30066 Cumbria CA11 9BN 1455 Canton Road +44 1768 868 995 (770) 973-5225 ALTO France S.A. Strasbourg B.P. 44, 4 Place d’Ostwald...
- Page 44 (b). Return the product to the nearest Clarke repair location. Transportation charges to and from the repair location must be prepaid by the purchaser. (c). Clarke will repair the product and or replace any defective parts without charge within a reasonable time after receipt of the product.
