- Page 1 VACUUM EXTRACTOR MODEL NO: CWVE1 PART NO: 6471168 OPERATING & MAINTENANCE INSTRUCTIONS GC0916...
-
Page 2: General Safety Precautions
INTRODUCTION Thank you for purchasing this CLARKE Workshop Vacuum Extractor. Before attempting to use this product, please read this manual thoroughly and follow the instructions carefully. In doing so you will ensure the safety of yourself and that of others around you, and you can look forward to your purchase giving you long and satisfactory service. - Page 3 4. Never use a power product if any part is damaged. Have it inspected and repaired by your Clarke dealer. Do not use if the electric cable, plug, or the machine itself, is in poor condition.
-
Page 4: Safety Symbols
14. Do not attempt to repair or modify the dust extractor or attempt any electrical repair yourself. Consult a qualified electrician or the Clarke Service Department on 020 8988 7400. SAFETY SYMBOLS... -
Page 5: Electrical Connections
ELECTRICAL CONNECTIONS WARNING! READ THESE ELECTRICAL SAFETY INSTRUCTIONS THOROUGHLY BEFORE CONNECTING THE PRODUCT TO THE MAINS SUPPLY. Before switching the product on, make sure that the voltage of your electricity supply is the same as that indicated on the rating plate. This product is designed to operate on 230VAC 50Hz. - Page 6 COMPONENTS When unpacking please check contents and advise your dealer immediately if any parts are missing. The essential components are as follows; Description Description Inlet Hose Tapered Hose Connector Dust Container Straight Hose Connector Retaining Band Filter Cartridge On/OFF Switch Filter Bags Motor Casing Inlet Adaptor Set (dims shown)
- Page 7 ASSEMBLY 1. Place filter cartridge (1) into a filter bag (2) as in Fig 1. 2. Fold any overhang into the filter cartridge. 3. Push the filter cartridge (1) complete with bag (2), onto the fan housing part of the motor casing (3).
-
Page 8: Operating And Maintenance
Ensure the hose is kept in good condition. A damaged hose will seriously effect the efficiency of the dust extractor and should be replaced. Contact your CLARKE dealer for replacements. CARE & STORAGE 1. When not in use, switch off and unplug from the power supply and ensure the power cable is not left as a hazard for persons to trip over. -
Page 9: Troubleshooting
Machine runs but fails to Low voltage or motor Have machine repaired reach full speed. defective. by your Clarke dealer Motor fails to develop Supply circuit overloaded. Use different circuit. full power. Extension lead unsuitable. Replace extension lead. -
Page 10: Parts Diagram
PARTS DIAGRAM Pos No Description Pos No Description Container Power Cable with Plug Retaining Band On/Off Switch Cartridge Filter Cable Gland Motor Assembly Spring Washer 5mm Screw 5.5 x 15 Washer 5mm Container Lid Rubber Seal Screw 5.5 x 15 Filter Bag Outer Sponge Belt Hose Connector... -
Page 11: Declaration Of Conformity
DECLARATION OF CONFORMITY Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
