Installation; Changing Remote Control Battery - Eneo VMC-8.4LCD-CP Installation And Operating Instructions Manual

7. Installation

1. Before installing the monitor, thoroughly clean the designated surface. It must be free of dust and grease.
2. Fix the monitor base to the desired location by either sticking it down firmly (an adhesive strip can be found
on the underside of the monitor - remove the protective strip first!) and/or screw it down tightly with the
enclosed screws.
3. From above, place the monitor on the monitor base support and adjust it using the thumb screw.
To get a perfect view of the monitor, angle the monitor by loosening the clamping screw and tighten it once
again when the desired position is found.

8. Changing Remote Control Battery

1. Slide and open the battery cover.
2. Insert new battery (CR2025) and ensure that
the polarities are correct when inserting ein.
3. Slide and close the battery cover.
Stand base
Thumb screw
Clamping screw
27
