Summary of Contents for Galaxy Audio DHT Any Spot
-
Page 2: Table Of Contents
Troubleshooting..........8 Specifications............9 Introduction Introduction Thank you for choosing the Galaxy Audio DHT Wireless Microphone System. You have joined hundreds of thousands of other satisfied Galaxy customers. Since 1977 Galaxy Audio’s professional experience in design and manufacturing ensure our products quality, performance and reliability. -
Page 4: Dht Receiver Features
Functions of the DHTR Receiver Functions of the DHTR Receiver DHTR Receiver Features Front Panel 4 5 6 Infrared (IR) Window. ASC Sync Button. Press to initiate IR connection between receiver and transmitter. Antenna A indicator light. System Menu Down Button. Indicates when Antenna A is active . -
Page 5: Hh76 Handheld Transmitter
HH64/HH64SC Handheld Transmitter HH64/HH64SC Handheld Transmitter Functions: Super Cardioid with Condenser Element Cardioid Dynamic Element LCD screen Please See “system setup ” on page 7. Power Switch Microphone Input Sensitivity Control. Left turn for output level decrease, right turn for output level increase. IR port Receivers infrared beam to synchronize frequencies. -
Page 6: Mbp76 Body Pack Transmitter
MBP76 Body Pack Transmitter MBP76 Body Pack Transmitter Features Antenna. LCD panel. Please see (System Setup) on Page 8. Power/ASC/ Low Battery Indicator. Constant Green: Power ON. Flashing Green: IR ASC in progress, or Low Batteries. Mute Indicator. Constant Red: Audio Muted. Power/Mute Button. -
Page 7: System Setup
System Setup System Setup Receiver Programming Group and Channel Selection: Press and Hold the SET button. The FREQ GROUP CHANNEL SCAN Group number will flash. Press to choose the appropriate frequency group, as shown on the left ; press (SET) again , (CHANNEL) flashes, press to choose the appropriate channel, as shown on the left For best results when operating multiple systems, set all systems to a... -
Page 8: Setting Up Multiple Receivers
Setting up multiple receivers Setting up multiple receivers Using the auto scan function to find clear frequencies for your DHT System 1) Power on any pre-existing wireless systems and transmitters except the first DHT system. 2) Power on the first DHT Receiver. 3) The Control and set buttons are on the front of the receiver. -
Page 9: Rack-Mounting The Receivers
Rack Mounting Rack Mounting Rack-Mounting the Receiver Included Single Rack Ears BNC CONNECTOR & CABLE: For front mounting antenna to rack ears. Part# AS-EXT50/BNC (optional) Rack Shelf for mounting Two Receivers side by side MRTD/P/T (optional) -
Page 10: Troubleshooting
Troubleshooting Troubleshooting Tips for Improving System Performance Maintain a line of sight between transmitters and antennas. Avoid placing the receiver near metal surfaces or any digital equipment (CD players, computers, etc). Keep the receiver away from the wall and at least 1m from the ground. Cellular telephones and two-way radios can interfere with the operation of wireless systems. -
Page 11: Specifications
Specifications Specifications System Body Pack Transmitter: Frequency Range: CODE D 584~607 MHz Max Audio Input Level: 0 dBV maximum at mic gain position. CODE L 655~679MHz +10 dBV maximum at 0 dB gain position. Transmitter Output level 10 dBm +20 dBV maximum at 10 dB gain position. Band: UHF Gain Adjustment Range: 30dB Operating Range Under Typical Conditions: 300'... -
Page 12: Visit Www.galaxyaudio.com
WARRANTY Information can be viewed online at http://www.galaxyaudio.com/warranty.php Specifications in this manual are subject to change without notice. For the most up to date manual and information visit www.galaxyaudio.com. 1-800-369-7768 www.galaxyaudio.com © Copyright Galaxy Audio 2014 V20140625 Printed in China...
