Summary of Contents for dji FlameWheel550
-
Page 2: Disclaimer
Read this disclaimer carefully before using FlameWheel550. By using this product, you hereby agree to this disclaimer and signify that you have read them fully. FlameWheel550 is an excellent multi-rotor. With a good autopilot, it will even offer tremendous flight features for low altitude flight working in restricted space. -
Page 3: Table Of Contents
Assembly ........................6 Product Usage Cautions When flying, the fast rotating propellers of FlameWheel550 will cause serious damage and injury. Therefore, please fly with a high safety consciousness. Keep flying multi-rotor away from objects, such as obstacles, human beings, high-voltage lines and so on. -
Page 4: In Box
In Box Top Board 550FBT ×1 Bottom Board 550FBB ×1 Arms 550FAC ×4 550FAW ×2 10in Propeller Pairs 550P10×3 Motors 550MOT ×6 ESC 550ESC ×6 OPTO Screws 550-M3×8 ×24 Screws 550-M2.5×5 ×36 Magic Strap 550MSX ×1, Battery Band 550BBX ×1... -
Page 5: Tools Needed
Tools Needed Hex Wrench 2.0mm: For frame installation. Screw Glue For fastening screws. Nylon Cable Tie Scissors For binding devices and wires. Diagonal Cutting Pliers Foam Double Sided Adhesive Tape For fixing receiver, controller and other modules. Soldering-iron & wires For connecting ESCs’... -
Page 6: Assembly
Assembly Screws Top Board M2.5×5 ① ② ⑥ ③ Screws M3×8 ⑤ ④ Bottom Board Step 1 Step 2 Step 3 Step 4 Step 5 Install bottom board Install autopilot system Install motors, ESCs Install top board Install propellers Install screws by appropriate force Please install propellers after autopilot system ·... -
Page 7: Specifications
Throttle stick is not at bottom Input signal abnormal B---------B---------B… Input voltage abnormal BB----BB----BB----BB…. Tips: DJI ESCs are specially designed for multi-rotors. When use with DJI autopilot systems, you do not have to setup any parameters or calibrate travel range. Specifications Frame Diagonal Wheelbase 550mm... - Page 8 Sales: sales@dji-innovations.com Technical support: support@dji-innovations.com Others: info@dji-innovations.com DJI FLAME WHEEL is registered trademark of Dajiang Innovation Technology Co. Ltd. Names of product, brand, etc., appearing in this manual are trademarks or registered trademarks of their respective owner companies. This product and manual are copyrighted by Dajiang Innovation Technology Co.
