FlameWheel450
User Manual
V 1.9
www.dji-innovations.com
©2012 DJI Innovations. All Rights Reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FlameWheel450 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for dji FlameWheel450

Summary of Contents for dji FlameWheel450

  • Page 1 FlameWheel450 User Manual V 1.9 www.dji-innovations.com ©2012 DJI Innovations. All Rights Reserved.

  • Page 2: Disclaimer

    This product and manual are copyrighted by DJI Innovations with all rights reserved. No part of this product or manual shall be reproduced in any form without the prior written consent or authorization of DJI Innovations. No patent liability is assumed with respect to the use of the product or information contained herein.

  • Page 3: Table Of Contents

    ESC Sound Introduction ....................7 Specifications .........................7 Product Usage Cautions When flying, the fast rotating propellers of FlameWheel450 will cause serious damage and injury. Therefore, please fly with a high safety consciousness. Keep flying multi-rotor away from objects, such as obstacles, human beings, high-voltage lines and so on.

  • Page 4: In Box

    8in Propeller Pairs 450P08×2 Motors 450MOT ×4 ESC 450ESC ×4 OPTO Screws 450-M3×8 ×16 Screws 450-M2.5×6 ×24 Magic Strap 450MSX ×1, Battery Band 450BBX ×1 Power Line Pair 450PLP ×1, Small Wrench 450SW ×1 ©2012 DJI Innovations. All Rights Reserved.

  • Page 5: Tools Needed

    Make sure the rotation direction of each motor is the same as the way in the figure of “ ” shows. If not, switch any of two wire connections of the incorrect motor to change Assembly its rotation direction. ©2012 DJI Innovations. All Rights Reserved.

  • Page 6: Assembly

    You'd better choose the same color arms for the same direction. See from top, motors on arms ①③ rotate counter-clock wise, use propellers 8045/1045; motors on arms ②④ rotate clock wise, use propellers 8045R/1045R. ©2012 DJI Innovations. All Rights Reserved.

  • Page 7: Esc Sound Introduction

    Throttle stick is not at bottom Input signal abnormal B--------B--------B… Input voltage abnormal BB---BB---BB---BB… Tips: DJI ESCs are specially designed for multi-rotors. When use with DJI autopilot systems, you do not have to setup any parameters or calibrate travel range. Specifications Frame Diagonal Wheelbase 450mm...
