  • Page 1 Spreading Wings S800 User Manual V 1.6 2012.10.25 修改 www.dji-innovations.com ©2012 DJI Innovations. All Rights Reserved.

  • Page 2: Disclaimer

    Read this disclaimer carefully before using Spreading Wings S800. By using this product, you hereby agree to this disclaimer and signify that you have read them fully. Spreading Wings S800 is an excellent multi-rotor. With a good autopilot, it will offer tremendous flight features. Despite the controller of DJI...

  • Page 3: S800 Profile

    Spreading Wings S800 is a multi-rotor designed for AP. It quick disassembling. Frame arm integrates with ESC and motor. With DJI WKM autopilot system, it can achieve hovering, cruising and other flight elements. S800 can be applied for aerial photography and other aero-modeling activities.

  • Page 4: Table Of Contents

    Mount Frame Arms ......................9 Mount Bi-pod ........................ 11 Assembly ........................13 ESC Sound ........................14 Specifications ....................... 14 Appendix ........................16 Mount Battery Bracket ................... 16 Trouble Shooting ....................17 Spare Parts Listing ....................18 ©2012 DJI Innovations. All Rights Reserved.

  • Page 5: Product Usage Cautions

    Notice matching the indications is very important, please pay attention to them. Flight Attention  With DJI WKM autopilot system, make sure the output signal of WKM F1~F2 and M1~M6 are all normal, to avoid serious damage(s) and injuries. ...

  • Page 6: In Box

    2.0mm Hex Wrench, 2.5mm Hex Wrench For mounting screws. Screw Glue For fastening screws. Nylon Cable Tie Scissors For binding devices and wires. Diagonal Cutting Pliers Foam Double Sided Adhesive Tape For fixing receiver, controller and other modules. ©2012 DJI Innovations. All Rights Reserved.

  • Page 7: Center Frame Wiring

     Markings stand for the propeller rotation direction. means clock-wise, and means counter clock-wise.  If you need other lead connector, please cut the original connector and solder on the new connector. (But not Recommend) ©2012 DJI Innovations. All Rights Reserved.

  • Page 8: Mount Center Frame

    Step1: Mount IMU module into IMU position in the center frame. Ensure IMU casing is out of touch the top board edge, as vibration can cause IMU mal-function. Step2: Please mount DJI Autopilot System parts onto the bottom board (not including GPS modules). Please remove all the screws from the bottom board first if necessary.

  • Page 9: Mount Frame Arms

    Step4: Press down the buckle to lock the arm. Make sure the arm does not move. Step5: Make sure the buckle is pressed down correctly, about 35 under normal circumstances. Notices:  Please add some lubricant at the position if it is hard to press down the buckle. ©2012 DJI Innovations. All Rights Reserved.
  • Page 10  LED is on after motor start. Examination Arms①②are aircraft nose direction, arms④⑤ are aircraft tail. See from top, motors on arms①③⑤ rotate counter clockwise; motors on arms②④⑥ rotate clockwise. ② ③ ① ④ ⑥ ⑤ ©2012 DJI Innovations. All Rights Reserved.

  • Page 11: Mount Bi-Pod

    (1) Fix (but not tighten) hexagonal socket head cap screws M2.5×5 (Fig.①) to H frame and bi-pod drawbar (Fig.①). (2) Adjust drawbar and T frame, and fix (but not tighten) hexagonal socket head cap screw M2.5×5 (Fig.②) to drawbar and aluminum ring 800AR. ©2012 DJI Innovations. All Rights Reserved.
  • Page 12 Put bi-pod on the flat floor to finish mounting smoothly and correctly.  Please mount the screws and use adequate screw glue.  Separate the bi-pod by disconnecting the H frame to make for easy carriage. Completed Quick Disassembly ©2012 DJI Innovations. All Rights Reserved.

  • Page 13: Assembly

     Ensure all knobs on the H frame aligned to the marks, and they would go through the arms successfully. Tips:  It is convenient for you to carry S800 by quick disassembly (Frame, Bi-pod, Frame and Bi-pod). ©2012 DJI Innovations. All Rights Reserved.

  • Page 14: Esc Sound

    Throttle stick is not at bottom Input signal abnormal B--------B--------B… Input voltage abnormal BB---BB---BB---BB… Tips: DJI ESCs are specially designed for multi-rotors. When use with DJI autopilot systems, you do not have to setup any parameters or calibrate travel range. Specifications Frame Diagonal Wheelbase 800mm...
  • Page 15 Flight Parameters Takeoff Weight 5.0Kg ~ 7.0Kg Load Weight 0Kg ~ 2.5Kg Power Battery LiPo (6S、10000mAh~15000mAh、15C(Min)) Max Power Consumption 2100W Hover Power Consumption 720W(@ Takeoff Weight 6Kg) Hover Time Max: 16 min (@10000mAh&6KgTakeoff Weight) ©2012 DJI Innovations. All Rights Reserved.

  • Page 16: Appendix

    Mount the retaining clip and the bracket, fix screws (but not tighten). M 2.5X5 Bracket Notch Outwards Retaining Clips Chamfer Outwards Step2: Place the mounting board and adjust its position, and then tighten all screws. Battery Mounting Board Parallel Parallel Parallel Correct ©2012 DJI Innovations. All Rights Reserved.

  • Page 17: Trouble Shooting

    Step3: Remount. Remount the screws on the top. Notices: Shim should be mounted in the correct position, as shim mount position of arm is different from arm Tips:  Please use adequate screw glue.  Install screws with appropriate strength. ©2012 DJI Innovations. All Rights Reserved.

  • Page 18: Spare Parts Listing

    & Red LED 2、3、5、7 4. CW & Green LED Notices:  The diagram is only for counter clockwise rotation propeller and frame arm. propeller and frame arm, it is S8010101B and S8010401B.  For clockwise ©2012 DJI Innovations. All Rights Reserved.
  • Page 19 M2.5X5 S8021101 S8021001 S8020901 S8020902 S8020903 S8020904 S8021102 M2.5X5 Name Components S8020901、S8020902、S8020903、S8020904 Arm Mounting Bracket S8021001 Center Frame Support Pillar S8021101、S8021102 Center Frame Top &Bottom Board S8021201 Top Board Cover for Arm Mounting Bracket ©2012 DJI Innovations. All Rights Reserved.
  • Page 20 S8031501、 S8031502、 S8031503、 S8031504、 H-Frame w/Bi-pod Top Mounting Hub 、 S8031505、S8031506 S8031507、13、14 S8031601、S8031602、S8031603 T-Frame(Right) S8031601、S8031602、S8031604 T-Frame(Left) S8031801 T-Frame Nonslip Damper (4pcs) S8031901 T-Frame Silicone Rubber Damper (4pcs) S8032001 Bi-pod Carbon Tube S8032101、S8032102(2pcs) 、S8032103 Bi-pod Drawbar ©2012 DJI Innovations. All Rights Reserved.
  • Page 21 Bi-pod Carbon Tube Bracket(Left Set) S8031505 S8031501、 S8031502、 S8031503、 S8031504、 Bi-pod Carbon Tube Bracket(Middle Set) S8031506 S8031501、 S8031502、 S8031503、 S8031504、 Bi-pod Carbon Tube Bracket(Right Set) S8031507 10pcs Screw Pack M2.5X5 10pcs Screw Pack M3X8 10pcs Screw Pack M2.5X8 ©2012 DJI Innovations. All Rights Reserved.
