Autostart AS-1585 SH Installation Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
M A N U A L
T R A N S M I S S I O N
R E M O T E
S T A R T E R
AS-1585 SH

Installation Guide

Notice
The manufacturer will accept no responsibility for any electrical damage resulting from improper installation of
the product, be that either damage to the vehicle itself or to the Unit. This Unit must be installed by a certified
technician using all safety devices supplied. Please note that this guide has been written for properly trained
Autostart technicians: a certain level of skills and knowledge is therefore assumed. Please review the
Installation Guide carefully before beginning any work.
Warning
manual
This Remote Car Starter is designed for vehicles with a
Transmission only. Before installing the
Unit, test that the OEM Door Switch contacts of the vehicle work well, and that the Parking Brake system
operates properly.
H.3.10.S.3.20
DOC: 2.21 – September 23, 2003 Gp CA Lp
Manufactured in Canada by Autostart
AS-1585 SH Installation Guide
P. 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AS-1585 SH and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Autostart AS-1585 SH

Summary of Contents for Autostart AS-1585 SH

  • Page 1: Installation Guide

    Unit. This Unit must be installed by a certified technician using all safety devices supplied. Please note that this guide has been written for properly trained Autostart technicians: a certain level of skills and knowledge is therefore assumed. Please review the Installation Guide carefully before beginning any work.

  • Page 2: Table Of Contents

    The following is a list of components included in the kit: – Remote Car Starter Control Unit – Super-heterodyne long-range Receiver – Antenna Interconnect Cable – multi-channel 5-button Remote Control – plug-in L.E.D. – six-pin 14 AWG Harness (Ignition Harness) P. 2 Installation Guide AS-1585 SH...

  • Page 3: Installation Points To Remember

    “splits” and connects to each device, a diode Always solder and tape all connections. is inserted on each of these lines. Keep the Antenna away from other types of Multiple or separate Door pin Connec- antennas (GPS/OnStar). tions: AS-1585 SH Installation Guide P. 3...

  • Page 4: Harness Description

    12 V source at the Ignition Switch (the 12 V wire is too small to supply the necessary current). In such cases, it is recommended to use the fuse box or the B+ connection on the Battery. P. 4 Installation Guide AS-1585 SH...
  • Page 5 (the Chassis or the true Body ground). It is (–) preferable to use a factory ground bolt rather than BLACK Chassis ground a self-tapping screw. Screws tend to get loose input or rusted over time and can cause erratic problems. AS-1585 SH Installation Guide P. 5...
  • Page 6 Programmable 500 mA negative output: 1/10-sec., BROWN (–) Lock output 7/10-sec. or 4-sec. pulse Programmable 500 mA negative output: 1/10-sec., 7/10-sec., 4-sec. or double 1/4-sec. pulse (ON GREEN (–) Unlock output 250 ms, OFF 500 ms, ON 250 ms). P. 6 Installation Guide AS-1585 SH...
  • Page 7 Connect to the negative Parking Brake Indicator Light wire of the vehicle. This wire is found at the (–) Parking Brake parking brake lever itself. ORANGE input Note: The wire should test ground when the Parking Brake is engaged. AS-1585 SH Installation Guide P. 7...
  • Page 8 Remote Car Starter shuts down, (–) Ground Out WHITE When Running e.g.: when the Run Time has expired, when the STOP button has been pressed, etc. This output can be used to activate external relays, bypass kits, etc.. P. 8 Installation Guide AS-1585 SH...
  • Page 9 Engine if the Glow-plug Light is still on after the 18-sec. delay (25 sec. when the Run Time is set to 30 min.). A Note on the Diesel Glow-plug Indicator Light: AS-1585 SH Installation Guide P. 9...
  • Page 10 Ignition circuit and wait to engage the Starter Motor while the Glow-plug indicator light is still The Remote Car Starter will engage the Starter Motor as soon as the Glow-plug light (+) goes out. P. 10 Installation Guide AS-1585 SH...

  • Page 11: Flashing The Hood Pin Switch

    20-second delay, the Remote Car Starter will exit Programming Mode and the installer will have to flash the Hood Pin switch once more. As long as the Hood is up, you may use the Programming Assistance Button instead of the Hood Pin switch. AS-1585 SH Installation Guide P. 11...

  • Page 12: The Programming Assistance Button

    Engine compartment. Caution The Hood Pin switch must be installed and connec- ted in order for the Programming Assistance Button to function. The button will work only when the Hood is up. P. 12 Installation Guide AS-1585 SH...

  • Page 13: Programming A Transmitter

    ....to access Mode 3. TRUNK The Parking Lights will flash and the Horn will honk once, twice or three times to confirm entry into a Mode. 3. Release the Brake Pedal. Table 3: Accessing modes AS-1585 SH Installation Guide P. 13...

  • Page 14: Programming Options

    Arming (3 min.) PASSIVE FUNCTION 4 – Door lock pulse timing OPTION 1* 7/10-sec. Lock/Unlock pulses OPTION 2 4-sec. Lock/Unlock pulses OPTION 3 7/10-sec. Lock pulse and two 1/4-sec. Unlock pulses OPTION 4 1/10-sec. Lock/Unlock pulses P. 14 Installation Guide AS-1585 SH...
  • Page 15 Priority Door Access FUNCTION 5 – External Trigger OPTION 1 Zone 3 disarm/rearm (Trunk Pin: a disarm pulse is sent before the Trunk opens, the vehicle rearms 4 seconds after the Trunk is closed). AS-1585 SH Installation Guide P. 15...

  • Page 16: Tach Programming

    1. Make sure that all the connections are properly made and that the Remote Car Starter is powered up. 2. With the Hood up (ground on the Hood Pin switch line), start the vehicle using the Key. 3. Allow the vehicle to reach regular Engine idle speed. P. 16 Installation Guide AS-1585 SH...

  • Page 17: Horn Honk Timing

    2. With the Engine already running, apply the Parking Brake and release the Brake Pedal. Make sure to release the Brake Pedal. 3. Within 20 sec. push on the Transmitter. LOCK UNLOCK START The Parking Lights will flash 3 times quickly and remain lit. AS-1585 SH Installation Guide P. 17...
  • Page 18 Mode. When setting the Remote Car Starter into Valet Mode, pressing the Lock button will lock the Doors without activating the Starter Kill. (Refer to the User Guide for further information on Valet Mode.) Idle Mode. Make sure the Vehicle properly enters and exits Idle Mode. P. 18 Installation Guide AS-1585 SH...

  • Page 19: Closing Up

    When testing to determine the type of Clutch circuit, it is recommended that you use a computer-safe logic probe. Some vehicles may also have a separate or combined switch on the Clutch pedal for cruise control. Usually, a cruise-control switch reacts at the AS-1585 SH Installation Guide P. 19...
  • Page 20 You should now be able to turn the key to the position and engage the start motor, with out pressing in the clutch pedal. If there is START P. 20 Installation Guide AS-1585 SH...

  • Page 21: Ignition-Controlled Door Locks

    Ignition Key is turned back to the position. If Ignition Lock Only is selected, the system will only all Doors when the Brake Pedal LOCK is pressed while the Ignition Key is in the position. IGNITION ON (RUN) AS-1585 SH Installation Guide P. 21...

  • Page 22: Secure Lock

    The Starter Kill circuit can be set to arm in either Passive Mode or Active Mode Caution!!! When installing the Starter Kill, it is extremely important that pin 86 be wired to Ignition: do not jump it to pin 30 (damage to the vehicle could result). P. 22 Installation Guide AS-1585 SH...

  • Page 23: Passive Or Active Arming

    While the Parking Lights are on, immediately push the Pin-switch 3 more times (down-up / down-up / down-up). The Parking Lights and L.E.D. will flash the five events stored in memory. Table 12: Events playback AS-1585 SH Installation Guide P. 23...

  • Page 24: Start Failure Codes Through The Parking Lights

    4 x = Brakes 5 x = No Tach Cut-off 6 x = Hood 7 x = Engine Running, no Ignition detected, or Tach before Start Note: “ ” stands for one flash of the Parking Lights P. 24 Installation Guide AS-1585 SH...

  • Page 25: Diagnostics - Parking Light Flash Table

    If the unit gives irregular signals (1 to 10 flashes followed by a pause, Irregular followed by further flashes), the system is playing back Start Failure Codes. This occurs when the Hood Pin-switch is pressed three times. Constant Panic Mode was triggered. flashes up to 30 sec. AS-1585 SH Installation Guide P. 25...
