Installation Guide
Introduction ...................................................2
Included in the Package ...............................2
Before You Get Started...........................3
Harness Description .....................................4
6-Pin Main Ignition Harness.....................4
5-Pin Secondary Harness........................5
12-Pin Accessories Harness....................5
Flashing the Hood Pin ..................................8
PAB.) ............................................................9
Before Programming a Transmitter ..............9
How to Program the Transmitter. .................9
Programming Options.................................10
Auto Tach Programming Procedure ...........11
Multi-Speed Tach Programming.................11
Testing ........................................................11
Please note:
Button is for the
LOCK/UNLOCK
Button
is for the
START/STOP
Buttons &
(together) is for the
The LED is NOT included in this model.
Notice
The manufacturer will accept no responsibility for any electrical damage resulting from improper
installation of the product, be that either damage to the vehicle itself or to the Unit. This Unit must
be installed by a certified technician using all safety devices supplied. Please note that this guide
has been written for properly trained Autostart technicians, a certain level of skill and knowledge is
therefore assumed. Please review the Installation Guide carefully before beginning any work.
Warning
This Unit is designed for vehicles with an automatic Transmission only. Before installing the
Unit, test that the vehicle does not start when the gear select lever is in the "Drive" position. If it
starts in gear, install a manual-transmission car starter instead.
DOC.1.01
H.3.10.S.3.20
T R A N S M I S S I O N
R E M O T E
S T A R T E R
AS-1412
Table of Contents
Closing Up..................................................12
Supplementary Information ........................12
Accessories or 2nd Crank Output) .............12
Ignition-controlled Door Locks...............13
Secure Lock...........................................13
Lock Pulse Duration ..............................13
Engine Run Time...................................13
Idle Mode...............................................13
valet)...........................................................13
plug-in valet) ...............................................14
functions.
functions.
release function.
TRUNK
- September 2, 2003 - CA
M U L T I -
S Y S T E M
Manufactured in Canada by Autostart
