A U T O M A T I C T R A N S M I S S I O N R E M O T E S T A R T E R
S Y S T E M
AS-1535 SH

Installation Guide

Notice
The manufacturer will accept no responsibility for any electrical damage resulting from
improper installation of the product, be that either damage to the vehicle itself or to the
Unit. This Unit must be installed by a certified technician using all safety devices
supplied. Please note that this guide has been written for properly trained Autostart
technicians, a certain level of skill and knowledge is therefore assumed. Please review
the Installation Guide carefully before beginning any work.
Warning
automatic
This unit is designed for vehicles with an
Transmission only.
Before installing the Unit, test that the vehicle will not start if the gear select lever is in the
"Drive" position. If the vehicle starts in gear, install a manual-transmission Car Starter
instead.
H.2.40 S.3.00
Rev.
DS CA –
June 23, 2003
Manufactured in Canada by Autostart
